Product Brief:

  • Supports 8th Generation Intel Core Processors (Socket 1151)
  • Digital PWM, 10 Power Phase
  • Supports DDR4 4266+(OC)
  • 2 PCIe 3.0 x16, 4 PCIe 3.0 x1, 1 M.2 (Key E)
  • NVIDIA® Quad SLI™, AMD 3-Way CrossFireX™
  • Graphics Output Options : HDMI, DVI-D
  • 7.1 CH HD Audio (Realtek ALC892 Audio Codec)
    Nichicon Fine Gold Series Audio Caps
  • 6 SATA3, 2 Ultra M.2 (PCIe Gen3 x4 & SATA3)
  • 9 USB 3.1 Gen1 (1*Front Type-C, 2*Front Type-A, 1*Rear Type-C, 5 Rear)
  • Intel® Gigabit LAN, Intel® 802.11ac WiFi + BT 4.2
  • ASRock RGB LED
Z370 Z370Z370

Dual Ultra M.2 For SSD
Two of the world's fastest PCIe Gen3 x4 Ultra M.2 slots that deliver up to 32Gb/s transfer speed, it also supports SATA3 6Gb/s M.2 modules.

Front USB 3.1 Gen1 Type-C
Front USB 3.1 Gen1 Type-C header delivers super fast data transfer rate and next generation reversible USB design to the front panel of computer case.

Intel® 802.11ac WiFi & LAN port
Intel LAN provides the best throughput performance, and user may also choose 802.11ac wireless connections.

RGB LED
Build your own colorful lighting system! ASRock RGB LED allows users to connect LED strip and create their unique PC style easily.

PCI-E Steel Slots :
Tailor-made for multiple VGA cards

The advanced PCI-E Steel Slots packed with solid cover that prevent any signal interference with graphics cards. It also ensures the heavy graphics cards to be well-installed in the PCI-E slots safely.

ASRock Intel® 4-Layer Memory POOL Technology
POOL (Planes On Outer Layers) technology allows 4-layer boards to utilize stripline routing instead of micro-strip routing, making motherboard having better electrical properties and performance.

  • Premium 45A Power Choke
  • Premium Memory Alloy Choke
  • Nichicon 12K Black Caps
  • I/O Armor
  • Sapphire Black PCB
  • High Density Glass Fabric PCB
Z370
