External USB Ports: 2 x USB Type-C (Support Thunderbolt 4 and USB 4 technology)
External Ports: 2 x mini DisplayPort IN ports
Compatibility: ASUS Intel 500 series and later models with 14-1 pin Thunderbolt header.
*Refer to ASUS official website for an up-to-date list of compatible models
Dimensions: 4.60" x 7.10"
Package Contents: 2 x mini DisplayPort cables (links graphics output from motherboard’s or discrete graphics card’s DisplayPort to the mini DisplayPort IN port on the ThunderboltEX 4 card)
1 x USB 2.0 cable
1 x 14-1 pin Thunderbolt header cable
1 x User manual
1 x Support DVD with Thunderbolt driver
External USB Ports: 1 x 9pin USB 2.0 pin header, 1 x USB Type-A female port
Standard: 1 x Low profile PCI-E
Specifications: Adapter card
Connector:
52pin Mini PCI-E connector
1 x 9pin USB 2.0 pin header
1 x USB Type-A female port
Bracket:
1 x Standard
1 x Low profile
Support voltage: 1.5V and 3.3V
Antenna
Type: Dipole
Gain(dBi):
2.4 - 2.5GHz 2dBi
5.1 - 5.8GHz 3dBi
Polarization: Linear Vertical
Radiation: Omni-directional
SWR <= 2.0
Impedance: 50 Ohms
Max power: 50W
Operating Systems Supported: Operating System Supported: Linux 2.6.32
Operating System Supported: macOS 10.6.8+
Operating System Supported: Windows 10
Operating System Supported: Windows 11
Operating System Supported: Windows 7
Operating System Supported: Windows 8
Operating System Supported: Windows 8.1
Operating System Supported: Windows Server 2012 R2
Operating System Supported: Windows Server 2016
Operating System Supported: Windows Server 2019
Operating System Supported: Windows Vista
Operating System Supported: Windows XP
Data Transfer Rate: FireWire 800 IEEE-1394b - 800 Mbit/s
Operating Systems Supported: Windows 2000, XP, Vista, 7, 8, 8.1, 10, Windows Server 2003, 2008 R2, 2012, 2016, Mac OS 10.6 to 10.12, Linux 3.5.x to 4.4.x LTS Versions Only
External USB Ports: 2 x USB Type-C (24 pin) USB 3.1 (10Gbps) Female
Internal Ports: 1 x SATA Power (15 pin) Plug
Standard: USB 3.1 Gen 2
Data Transfer Rate: up to 10 Gbit/s
Operating Systems Supported: Windows 7, 8, 8.1, 10
Windows Server 2008 R2, 2012, 2016, 2019
Linux 3.5 to 4.11.x LTS version only
macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13)
Compatibility: PCI Express enabled computer or server with a PCI Express x4 slot or higher (x8, x16)
Specifications: Connector Type(s): 1 - PCI Express x4 Male
Bus Type: PCI Express
Card Type: Standard Profile (LP bracket incl.)
Chipset ID: ASMedia - ASM3142
Industry Standards: USB 3.2 Specification Rev. 2.0
USB Specification Rev. 2.0
PCI Express Base Specification Rev. 3.0
Intel xHCI Specification Rev...
Operating Systems Supported: DOS, Windows 95/ 98SE/ 2000/ XP(32/64bit)/ Server 2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Linux, and Mac OS 10.4.x and up
Windows XP Embedded/ POS Ready 2009/ Embedded System 2009 OS/ CE 5.0/ CE 6.0
Compatibility: Compatible with PCI-E Mini Card specification revision 1.2
Compliant with Serial ATA Specification 3.1
Supports communication speeds of 6.0 Gbps, 3.0 Gbps, and 1.5 Gbps
Package Contents: Mini PCI-Express to SATA Host Controller Card
User Manual
Sotware Driver CD
SATA Cable
External Ports: 2 - USB 3.0 A (9 pin; SuperSpeed) Female
Internal Ports: 1 - SATA Power (15 pin) Plug
2 - IDC (20 pin; USB 3.0; Motherboard Header) Receptacle
Standard: USB 3.0
Data Transfer Rate: Up to 5.0 Gbps
Operating Systems Supported: Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64)
Windows Server® 2012, 2008 R2
Linux 2.6.31 and up (Tested up to 3.5)
External Ports: 6 - USB 3.0 A (9 pin; SuperSpeed) Female
Internal Ports: 1 - SATA Power (15 pin) Plug
1 - USB 3.0 A (9 pin; SuperSpeed) Female
Standard: USB 3.0
Data Transfer Rate: Up to 5.0 Gbps
Operating Systems Supported: Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64)
Windows Server® 2012, 2008 R2
Linux 2.6.31 and up (Tested up to 3.5)
External USB Ports: 2 x USB 3.2 Gen 2x1 USB Type-A (9 pin, 10 Gbps)
1 x USB 3.2 Gen 2x1 USB Type-C (24 pin, 10 Gbps)
Internal Ports: 1 x IDC (20 pin, USB 3.0, Motherboard Header)
1 x SATA Power (15 pin)
Standard: Industry Standards:
PCI Express Base Specification Rev. 3.0
USB 3.2 Specifications
UASP (USB Attached SCSI Protocol) Rev. 1.0
Operating Systems Supported: Windows 7, 8, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016, 2019
Linux 3.5 to 4.11.x LTS version only
macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13) macOS Big Sur (11.0)
Compatibility: Windows 7, 8, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016, 2019
Linux 3.5 to 4.11.x LTS version only
macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13) macOS Big Sur (11.0)
