Specifications: Material: Plastic outer shell
Output limitation (each port):
Addressable RGB port: 72 LED per port, total 5V, 5A
Fan Port : total 12V, 3A
Color Selection: Support 2812 IC Addressable RGB LED
Signal output:
Standard Addressable RGB 3pin + 4-1pin x 6*
Fan 4pin port x 4 (compatible with 3pin)
Included Parts:
6 x Standard Addressable RGB cable
1 x Peripheral power Y cable
1 x RF remote
1 x Thermal sensor cable
1 x Power switch cable
Specifications: Material Plastic Shell
Signal input:
Standard addressable RGB 3Pin +5V, D, G*
Motherboard addressable RGB 4pin +5V, D, NP, G*
Signal output: SilverStone custom addressable RGB 3pin +5V, D, G** x 8
Power Input: SATA 15pin
Output limitation (each port): 5V 9A (4.5A+4.5A)***
Included Parts:
8 x Standard addressable RGB 3pin cable
1 x SATA power cable
1 x Input signal cable
Specifications: Material 12 pcs addressable RGB LED with magnetic strip and adhesive tape
Pin definition:
+5V, D, G*
+5V, D, NP, G*
Included Parts:
2 x Addressable RGB LED strip
1 x Motherboard connect cable**
1 x Splitter cable
Length: 300mm
Wattage: 3W (5V, 0.6A)
Tandem limits: Depend on controller
Remark:
* Please check the control box and motherboard pin header that you want to connect are the same as LS03’s pin definition.
** Included Motherboard connect cable supports SilverStone’s addressable RGB 3pin connectors and other market standard addressable RGB 3pin (three pin in four pin housing) connectors.
Specifications: Color: Blue
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Features: Flexible strip allows greater adaptation to any surface
Include multiple power connector for easy connection
Support daisy chaining multiple light strips
Include adhesive tape for easy installation.
Specifications: Material: SPCC with zinc plating
Max. supported weight: 45kg
Net weight: 2.2kg
Dimension: 570mm (W) x 45mm (H) x 24mm (D)
22.44" (W) x 1.77" (H) x 0.94" (D)
Specifications: Color: Black
Connectors: PWM 4pin connector x 1 to motherboard
SATA power cable x 1 to PSU
PWM 4pin header x 8, compatible with 3pin cable*
Length
PWM cable 500mm, SATA power cable 300mm
Capacitor size
2200µF
Dimension
54mm (W) x 19mm (H) x 40mm (D)
Specifications: Finding a quiet and efficient cooling fan is the ultimate goal for every enthusiast. The FF121 is a fan grille designed for easy installation with any 120mm fan. The honeycomb pattern on the grille not only reduces wind shear noise but also channels the airflow into more focused beam. Its integrated filter also provides reduced dust buildup to extend the life cycle of components. All in all, the FF121 is an excellent upgrade for any 120mm fans in your system
Specifications: Color: Black
Material: High density ABS / magnet
Application: 140mm fan grille and filter kit
Net Weight: 22g
Dimension: 140 mm(W) x 140 mm(H) x 3 mm (D)
Specifications: Color: Black
Material: EPOM
Dimension: 530 mm(W) x 380 mm(L) x 4 mm (T)
Building a silent computer is often a difficult goal for enthusiasts and power users to achieve, especially if the computer needs to also be fast and cool. The SF01 is a package of two foam pads designed to help absorb noise with minimal impact inside a computer chassis. Each pad has large surface area and high density 4mm thick foam to provide good noise reduction and flexible integration choices
