BZBGEAR 1080P FHD 20X HDMI/3G-SDI/NDI|HX/RS232/485/POE Live Streaming PTZ Camera with POE

The BG-ND-XHSRP is an enterprise-grade NDI-enabled HD PTZ camera designed for use in video conferencing and small-scale productions. The thoughtful selection of outputs allows this camera to integrate seamlessly with multiple configurations and workflows.

Connectivity & Features

Featuring a 1/2.8” HD CMOS sensor, the BG-ND-XHSRP produces vibrant images at resolutions up to 1080p@60Hz. This camera features simultaneous NDI|HX, 3G-SDI, and HDMI outputs. NDI Technology provides the winning combination of user-friendliness, high quality video, and maximum compatibility with other devices and software platforms. Lens options include 20X and 30X optical zoom levels.

Equipped with a 3.5mm audio input, the BG-ND-XHSRP provides the ability to embed stereo audio to the physical outputs and IP stream. In addition to NDI|HX2, the camera also supports ONVIF, RTSP, and RTMP streaming protocols.

What is NDI?

Network Device Interface (NDI) is a high performance AV over IP standard that allows anyone to use real time, ultra low latency video on existing IP video networks. The NDI open protocol enables professionals to share video through a local area network (LAN) with video-compatible devices. With a single ethernet cable connection, professionals can merge all stages of production from start to finish. That way, all production tasks and processes will be united, so accomplishing a creative vision will be simple. With the NDI 5.5 tool-kit, users will also be able to connect any audio device as an NDI source with NDI’s Audio Direct tool. This adds audio over IP to NDI’s revolution.

What is NDI|HX2?

NDI|HX2 is an updated version of NDI|HX1. NDI|HX2 also compresses the bandwidth, but is more efficient than NDI|HX1. With compressed bandwidth, users can have more devices on their LAN without running into latency issues. NDI|HX2 provides good quality output, low bandwidth and medium latency. The main difference compared to NDI|HX1 is that HX2 is truly a native NDI stream - all the way from the source device to the destination. This means it is a 'cleaner' implementation than HX1 and can potentially be more reliable, provide lower latency and give a more flexible connection which shares all the usual features of NDI.

Control

The BG-ND-XHSRP can be controlled via NDI, web browser, IR remote control, IP control (IP VISCA, ONVIF) RS-232/485 (VISCA/PELCO-P/D). 255 camera presets can be stored internally, of which 10 can be recalled using the IR remote control.

Features:

• Zoom - Available in 20x/30x optical zoom +10x Digital


• Control - IP (VISCA), IR, and cascadable RS232/485 (VISCA/PELCO-D/P) + 255 preset positions


• 3x Video Outputs - HDMI, 3G-SDI, and NDI/IP-streaming working simultaneously


• Latest Streaming Tech - Supports H.264/H.265 video compression and network protocols for live streaming


• Superb Auto Focus - Latest auto focusing algorithms resulting in quick, accurate, and stable focus


• NDI - Adoption of NDI® 4.0 from NewTek


• Remote upgrade, reboot and reset functions


• Low-noise 1/2.8" CMOS


• Adaptive high-accuracy step-driving motor


• Compatible with all NewTek NDI tools


• Advanced 2D/3D noise reduction


• Embed stereo audio with 3.5mm jack your IP streams


• Max FOV from 54.7° to 65.1° (dependent on zoom)


• RTMP and RTMPS streaming


• PoE LAN port allows for single cable installations
