Learn more about the GIGABYTE R263-Z30-AAC2
General| Brand | GIGABYTE |
|---|
| Model | R263-Z30-AAC2 |
|---|
| Form Factor | 2U Rackmount |
|---|
| Workload | General Purpose Server |
|---|
CPU Supported| CPU Type | AMD EPYC 9005 & 9004 Series |
|---|
| CPU Socket | Socket SP5 |
|---|
| Installed CPU | No CPU Installed |
|---|
| Max Processors | 1 |
|---|
| CPU Features | Single processor, cTDP up to 300W - At 30°C ambient, cTDP up to 400W |
|---|
Memory Supported| Memory Slots | 12 x 288Pin |
|---|
| Installed Memory Size | No Memory Installed |
|---|
| Memory Type Supported | RDIMM: Up to 4800 MT/s |
|---|
| Channel Supported | 12 Channel |
|---|
| Registered | Yes |
|---|
Storage Supported| Installed HDD | No Storage Installed |
|---|
| M.2 | 1 x M.2 (2280/22110), PCIe Gen3 x4 |
|---|
Graphics| GPU/VPU | Aspeed AST2600 |
|---|
Expansion Slots| PCI Express | 2 x FHHL PCIe Gen5 x16 slots 3 x FHHL PCIe Gen4 x16 and x8 slots 2 x OCP NIC 3.0 PCIe Gen5 x16 slots |
|---|
Communications| Max. LAN Speed | 1 Gigabit |
|---|
Expansion Bays| Hot-Swap Bays | Front side: 4 x 3.5"/2.5" Gen4 NVMe/SATA/SAS 8 x 3.5"/2.5" SATA/SAS |
|---|
Panel Ports| Buttons | 1 x NMI button 1 x Reset button |
|---|
| LEDs | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs (1 x LED disabled) 1 x Storage activity LED 1 x System status LED |
|---|
| Front USB | 2 x USB 3.2 Gen1 ports (Type-A) |
|---|
| DisplayPort | 1 x Mini DisplayPort |
|---|
| Rear USB | 2 x USB 3.2 Gen1 ports (Type-A) |
|---|
| RJ45 | 1 |
|---|
| Other Ports | 1 x MLAN |
|---|
Power Supply| Max. Power | 1+1 1300W 80 PLUS Platinum redundant power supplies |
|---|
Cooling| Fans | 4 x 80x80x38mm (18,300rpm) |
|---|
Environment| Temperature | Operating temperature: 10°C to 35°C Non-operating temperature: -40°C to 60°C |
|---|
| Humidity | Operating humidity: 8%-80% (non-condensing) Non-operating humidity: 20%-95% (non-condensing) |
|---|
Dimensions & Weight| Dimensions | 3.44" x 17.24" x 27.95" |
|---|
Packaging| Package Contents | 1 x R263-Z30-AAC2 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 1 x 2-Section Rail kit |
|---|
Additional Information| First Listed on Newegg | February 10, 2025 |
|---|
