NEC X555UNS 55" Ultra Narrow Bezel S-IPS 3x3 TileMatrix Video Wall Solution - X555UNS-TMX9P - Qty 9

NEC's complete 55" 3x3 LCD TileMatrix™ Digital Video Wall Solution delivers an all-in-one, easy-to-configure and cost-effective solution that is ideal for dynamic digital signage, information display and command & control applications. Exclusive TileMatrix and TileComp™ technologies, combined with the ultra-narrow bezel design of the NEC X555UNV and the full adjustment capabilities of the Peerless DS-VW765-LAND mount, provide for a near seamless video wall without the need for additional third-party equipment.

• Bundled solution with everything required for a 3x3 video wall makes configuration and installation easy
• Pull-out mount allows for full-service capabilities and 6-axis adjustment for perfect alignment
• Direct LED backlighting technology improves power consumption and uniformity
• Display wall calibration kit, Overframe Bezel Kit, cabling and null modem cabling complete the solution
• Overnight onsite exchange warranty ensures minimum downtime for maximum impact
• Auto ID feature reduces install time in the single press of a button
• Expanded daisy chain options with DP1.2 enables 4K resolution across entire wall
• OPS Slot for internal media player or PC compatibility
• Near field communication capabilities for setup and service
• NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
• Video daisy chain limitations apply when High-bandwidth Digital Content Protection (HDCP) is utilized

The Ideal Video Wall Display

Transform your video walls with the crystal clear imagery of the NEC 55" X555UNS and X555UNV. Brand new S-IPS panel technology provides exceptional viewing angles and top of the line color depth to enhance image quality for all types of installations. On top of that, direct LED backlighting not only reduces power consumption and improves edge-to-edge brightness uniformity but also allows for localized dimming capabilities that will control the backlighting and ultimately improve contrast ratio based on the current content shown on the display. Mere millimeters separate content from display to display which ensures a smooth transition across a video wall. This display is ideal for digital signage, boardrooms, entrance lobbies and broadcast applications, and can be deployed in video wall applications up to 10 x 10 in size utilizing integrated TileMatrix™ technology*. TileMatrix technology within these displays can also now support up to UHD (3840 x 2160) resolution through the internal daisy chain functionality and still show imagery across the entire video wall. This is 4x the resolution that previous generations of product would support.

S-IPS Panel and an Ultra Narrow Bezel

Brand new S-IPS panel technology allows for 10-bit color depth and far less off-angle color shift compared to typical video wall displays. On top of that, mere millimeters separate content from display to display, which ensures a smooth transition across a video wall. The X555UNS and X555UNV minimize that distance to a ground-breaking 3.5 mm.

Auto TileMatrix, Auto ID and Auto IP Address Technology

Auto TileMatrix and ID features allow a user to simply set up the size of the video wall on the first display and automatically scale the content across the remaining displays. Auto IP Address simplifies control setup by setting the static IP address on the first display then initiating the feature so that the IP Addresses of consecutive displays following the LAN daisy chain.

DisplayPort UHD Daisy Chain Functionality

These displays have the ability to input a UHD/30Hz signal via HDMI or DisplayPort then also output the same signal across the entire wall. This allows TileMatrix to support up to 4x the resolution as previous generation products.

Advanced Heat Management

Monitoring and managing the temperature of each display is crucial to secure reliability and longevity. An industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics, and fan-based technology allows for 24/7 operation, and protects your display investment.

Without heat management, the displays placed higher on a wall will sustain a hotter temperature than the screens below. This damaging heat will lower the picture quality and life expectancy of the product. However, NEC’s advanced heat management ensures heat dissipation for a more uniform overall wall temperature. Integrated cooling fans automatically turn on and stay on when high internal temperatures are detected. These will stay on until the heat is properly dissipated and the display remains under proper temperature thresholds.

Frame Comp Functionality

By allowing per row frame adjustment across the video wall, this feature allows for better content synchronization when content is moving across the video wall.

Human Sensor and Ambient Light Sensor

This new optional human (motion) sensor accessory (KT-RC2) helps to deliver creative digital signage to end users by allowing for dynamic control of brightness, audio and source inputs while saving operating costs. Auto dimming adjusts the backlight of the LCD automatically depending on the amount of ambient light.

Proof of Play

This function provides accurate proof that displays are working as established when checking from an external location. Information regarding video source, time on, audio source and more can be pulled through the display when coupled with NaViSet Administrator 2.

NaViSet Administrator 2

This software is an all-in-one remote support solution that runs from a central location and provides monitoring, asset management and control functionality of the majority of NEC display devices and Windows computers. It is ideal for multi-device installations over larger infrastructures.

Dedicated Color Calibration Software

As the brightness and color temperature of the LCD change with time, colors may not match across multiple screens. The NEC Display Wall Calibrator software ensures color uniformity and fidelity across multiple screens, creating a perfectly matched image in tiled environments.

Intelligent Wireless Data Function

The built-in near field communication (NFC) chip allows data to be read and written via a mobile phone or tablet PC. Users can significantly reduce installation costs as displays can be easily configured and serviced using the NEC NFC Android app. This is extremely useful for larger rollouts as it can be utilized even when the display is powered off.

Expansion slots

The NEC UN displays support Intel’s Open Pluggable Specification (OPS), and interface expansion slots to provide the flexibility customers need.

Input Panel

• 1. Vacation Switch
• 2. External Speaker Terminal
• 3. Audio Mini Jack Out
• 4. USB Service Port
• 5. LAN Ports
• 6. Audio Mini Jack In
• 7. RS-232C In
• 8. Remote In
• 9. VGA D-Sub In
• 10. DisplayPort In/Out
• 11. HDMI In
• 12. DVI-D In

Dimensions

Technical Specifications
