HANSEN B23AS37F Coupler Body,(F)NPT,1/4,Brass

The HANSEN - B23AS37F is a quick-connect hose coupling intended for use with pneumatic and fluid line applications. It provides a push-to-connect locking mechanism for coupling and uncoupling using a push-to-connect locking mechanism, when installed and used according to the manufacturers instructions. The coupling is intended to form a sealed joint for pneumatic and fluid line use and is compatible with pneumatic and fluid line applications within the specified ratings.

Key Features:

• - Compatibility: compatible with AR0210, Industrial Interchange, and Tru-Flate system connections, when matched to the specified thread and hose fitting sizes.
• - Size: Features a 3/8 in body size, hose fitting size, and coupling size with 3/8"-18 thread size.
• - Material and Finish: Brass construction with a zinc plated coating.
• - Connection Type: Female hose fitting with NPT threading.
• - Valve: Includes an integrated poppet valve to control fluid or air flow.
• - Seal Material: Nitrile sealing element.
• - Dimensions: Overall length of 2 in and a maximum outside diameter of 15/16 in.
• - Pressure and Temperature: maximum working pressure rating: 150 psi at 70°F and rated temperature range: -40°F to 250°F.
• - Maximum Flow Rate: maximum flow rate: 792 L/min.
