Blue Sea 7044 187 - Series Thermal Circuit Breaker - 100Amp

187 - Series Thermal Circuit Breakers - Panel Mount100
Amp Circuit BreakerPN:
  7044Features: Combines switching and circuit protection into a single deviceAll components meet SAE J1171 external ignition protection requirementsClear single lever operation"Trip Free" design cannot be held "ON" during fault current conditionWaterproofRecessed mounting holes for clean appearanceSelf-trimming case eliminates the need for mounting panels or trim bezelsRound case permits easy installation with standard sized hole sawLarge clearance around terminal studs accept heavy gauge wire lugsRobust 5/16 terminals provide high torque connectionsLarge lever with vertical/horizontal orientation provides indication of trip statusIgnition protected - safe for installation aboard gasoline powered boats
Specifications  Circuit Breaker Class: Type III - Switchable / Manual Reset -
Trip FreeType: Thermally
Responsive Bi-Metal BladeCase Material: Thermoset
PolyesterVoltage Rating: 48
Volts DC MaximumInterrupt Rating: 5000 Amperes @12 Volts DC  3000 Amperes @24 Volts DC  1500 Amperes @42
Volts DCOperating Temperature Range: -25C° to +82C°
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer birth defects or other reproductive harm. For more information go to P65Warnings. ca. gov.
Product: BLUE SEA 7044 CIRCUIT BREAKER 100A
Manufacturer: Blue Sea Systems
Manufacturer Part No: 7044
Product: BLUE SEA 7044 CIRCUIT BREAKER 100A
