InfiRay Phone Infrared Thermal Imager PCB Circuit Industrial Test Floor Heating Pipe Temperature for iPhone 15 series

Please note that this is the iPhone 15 series version!
Please confirm the model you have selected before placing an order. If you need an Android or iOS series, please click on our store to search and purchase.

Specifications

:
Model: P2 Pro with magnetic macro lens
Resolution: 256×192
NETD: 50mK@25°C, F# 1.0

Performance:
Frame Rate: 25Hz
Operating Temperature: -10°C~55°C
Storage Temperature: -40°C~85°C
Power Consumption: 350mW
Processor: Self-developed ASIC chip

Lens:
Focal length: 3.2 mm
Aperture: F 1.1
FOV: 56.0 °x 42.2 °
Focusing Mode: Athermalized Prime Lens
Macro Lens: Adaptable

Temperature Measurement:
Measurement Range: -20°C~ 600°C
Measuring Error: ±2ºC (±2% of reading, the greater shall prevail)
Temperature Correction: Emissivity, distance, environmental temperature

Shell:
Size: 27x18x 9.8 (mm)
Color: Silver
Weight: 9g
Interface: USB type C

Software Function:
Palette: White/black-hot + 6 palettes
Measurement Mode: Point/line/plane temperature measurement
Information Sharing: Instant picture sharing
Data analysis: Secondary temperature analysis and processing of images
Imaging Tool: iOS
Software Update: Online update
