FURUNO GP39 WAAS GPS RECEIVER

FURUNO GP39 WAAS GPS RECEIVERFuruno GP39 Color GPS/SBAS
Receiver Model: GP39
UPC: 611679364487 Newly designed GPS core delivers enhanced position fixing accuracy Bright 4.2 high-resolution color LCD (700cd) Storage for 3, 000 track points, 10, 000 waypoints and 100 routes SBAS capable for better positioning calculations Share and display position information on networked equipment such as a Fish Finder, Sonar, Radar, etc. NMEA0180 input port receives data from Fish Finder, Radar, etc. 7 display modes available, including 2 user-customizable modes Displays position data in Loran TD's USB port for importing/exporting waypoints and routes; Upload/download data in GPX format for easy transfer to TZtouch/TZtouch2 Click-In hanger for easy mounting/dismounting and uses no knobs - also perfect for overhead mounts
Multi-language ready: English, French, Spanish, Chinese, Vietnamese, Malay, Indonesian and Thai The FURUNO GP39 GPS Navigator provides accurate and reliable position fixing, thanks to a 12-channel GPS receiver combined with integrated SBAS (WAAS/EGNOS/MSAS) technology. The GP39 has various display modes, including Plotter, Highway, Steering, NAV data, and Satellite monitor, as well as 2 user-customizable display modes, allowing you to select which data you want displayed on its 4.2 color LCD. Up to 3, 000 points of ship track, 10, 000 waypoints and 100 routes (each with up to 30 waypoints) can be stored. The waypoint and route data can be exported/imported via a USB flash drive or signal converter. The GP39 can be networked with a fish finder, sonar, radar or other navigation equipment for feeding highly accurate navigation data. The GP39 receives the TLL (Target Latitude/Longitude) sentence from networked fish finders or sonars and can display the received information, allowing you to easily mark fish school locations. SpecificationsDisplay Size 4.2 Color LCD Resolution480 x 272 Display modePlotter, Highway, Steering, Nav Data, User display, Satellite monitor.

Memory capacity3, 000 ship's trac points10, 000 waypoints with comments 100 routes with 30 waypoints/route AlarmsArrical and anchor watch, Cross track error, Speed, WAAS, Time, and Trip GPS/SBAS Receiver type12 Channel Time to first fixApprox. 90 seconds cold start Accuracy GPS10m (95% of time, HDOP 4) WAAS3m (95% of time, HDOP 4) MSAS7m (95% of time, HDOP 4) Interface PortsNMEA0183 1 port, USB 1 port Input Voltage12-24 vDC Input Draw 0.7 - 0.3A mps What's in the
Box: GP39 Grey Hard Cover GPA017 Antenna Power Cable Fuse 1.5 amp x 2 Tapping Screw x 4
Mounting Bracket Operator's GuideWARNING: Cancer and Reproductive Harm - www. P65Warnings. ca. gov.
