Car Multimedia Player Double Din, Bluetooth Audio and Calling, 6.2 Inch LCD Touchscreen Monitor, MP5 Player, WMA, USB, SD, Auxiliary Input, FM Radio Receiver, Rear View Backup Camera

UNITOPSCI Car Multimedia Player - Double Din, Bluetooth Audio and Calling, 6.2 Inch LCD Touchscreen Monitor, MP5 Player, WMA, USB, SD, Auxiliary Input, FM Radio Receiver,Rear View Backup Camera

Built-in Bluetooth & Microphone, Supports Hands- free Callings
This double din car stereo supports bluetooth function, supports hands-free callings and receiver, solve your calling problem when you drive.
Built-in bluetooth for wireless audio streaming, connected to your phone to play the bluetooth music, enjoy your driving.

Using Mirror Link To Shows The GPS Navigation Images
PS.: The car radio doesn’t support GPS!

You can use your phone navigation function and screen mirroring function to show the GPS navigation image in the radio.
Only support android screen mirroring with android phone( 4.0-7.1 system).
This function can not work with Samsung phone.

Supported Rear View Camera Input
A Free Backup Camera Included In Package!

When your car at reverse gear, automatically switch reversing image on screen, can protect your parking and reversing safety.
IP 67 waterproof, 170° wide angle color lens shooting of rear view camera.

Multimedia Payback
Supported 1080P full HD Visual Experience

Support TF card, high speed USB2.0 interface compatible with U disk. Power-off with auto-memory store function under radio or SD/USB mode.
Compatible with video and audio playback, Audio playback: MP3 / WMA, WAV. Video playback: RM/RMVB/FLV / 3GP/MPEG/DIVX/XVID, DAT/VOB/AVI/MP4.

FM Radio Receiver
FM Radio Receiver: Tuning range: 87.5-108MHz

Variety of sound adjustment (SEL): electronic volume, treble, bass, left and right balance, front and rear sound field.
Hardware electronic sound (EQ) processing, a variety of audio modes, high and low tone can be adjusted;

Double Din Panel Size Car Radio
Panel Size: 178*65*100mm

Please check the size of car stereo to your car center console outline before purchase.
Or if you are not sure about this size, please send us a picture of yoru car center console.

Specification
Touch Screen size: 6.2 inch 1024*600
Voltage: DC 12V
Speaker impedance: 4ohm
Maximum power: 45W*4
Volume control: +/-8 dB(Bass 100HZ Treble 10KHZ), knob volume adjustment
Applicable sensitivity: 15dB
SNR(Signal to noise ratio): 50dB
Stereo Resolution: 30dB

Installation Tips
- The car stereo with working voltage of DC 12 V, please use the suitable voltage during installation or use.

- You will receive an manual within 24 hours after order placement. Please check your mailbox or your Amazon message box.

- If you don't have experience on wiring and installing the car stereo, please ask expert to complete this operation.

Troubleshooting:

Before install the car stereo to your car (especially when you want to hire an expensive professional), please make a simple test.
Please combine red and yellow line from power harness to a constant (+) 12 V power source, black to (-)12 V negative power source, then open the car radio.
If the car radio can be opened, it will work when you install it onto your car, unless your wire connection is wrong or some wrong operation had blown the fuse.
The wire harness offered without a blue cable. Note: The Amplifier function can be achieved by connecting the blue cable to the ACC wire(red cable on picture above) on wire harness.
