RedHat 1/8" NPT 2-Way Solenoid Valve 24VDC 1/16" Orifice ASCO U8256A002V

The ASCO U8256A002V is a compact, 2-way, 2-position solenoid valve with a normally closed starting configuration. Constructed with a brass valve body and FKM seals, it uses a direct acting operation to control the flow of air, inert gases, light oil, and water. The valve includes the coil and features an open frame enclosure with a coil insulation class F. It supports both horizontal and vertical mounting orientations and is intended for indoor use.

Key Features:

• - Connection Type: Inlet and outlet NPTF threaded ports, 1/8 in nominal pipe size
• - Dimensions: Overall length 1-5/16 in, width 1 in, height 2 in
• - Orifice Diameter: 1/16 in
• - Flow Capacity: Cv of 0.08
• - Differential pressure range: 0 to 220 psi for air, inert gas, light oil, and water
• - Electrical: 24 V DC voltage, 6.9 W coil wattage, 18 in lead electrical connections
• - Response Time: 20 milliseconds
• - Valve Design: Compact valve type, direct acting operation
• - Seals: FKM material
• - Environmental Ratings: IP66, NEMA 4 and 4X enclosure ratings
• - Includes coil and sealing components
