Kalea-INFORMATIQUE PCIe x4 Network Controller Card with 4 5 Gigabit RJ45 Ports Power Over Ethernet (PoE+) 30W Per Port, Realtek RTL8126 Chipset

HIGH PERFORMANCE CONTROLLER Based on the Realtek RTL8126 controller, this card features four independent 5Gbps Ethernet ports with PoE+ power supply up to 30W per port
Comprehensive compatibility: PCI Express Gen3 x4 for Gen 3.0 ports or higher in x4, x8 or x16 configuration. Operating systems supported: Windows, Linux. Supports IEEE 802.3 / 802.3u / 802.3ab / 802.3bz / 802.3x standards. PoE standard IEEE 802.3at (PoE+). Network cabling CAT6 / CAT6A / CAT7 up to 100 m
SPECIFICATIONS Realtek RTL8126 controller with 4 independent RJ45 ports. Throughput per port 100 Mbps / 1 Gbps / 2.5 Gbps / 5 Gbps. PoE power supply up to 30W per port, total PoE power up to 90W
Advanced management and protection features: PoE management via hardware and software control. Programmable PoE management and real-time monitoring tool. PoE protection by resettable electronic fuse (eFuse). Electric ESD protection 8 kV / surge protection 4 kV. Power connection via PCIe + ATX 12V input
Professional networking features: Multi-cue functions, Traffic Shaping, Advanced management. Support for PXE and Jumbo frames. LED indicators for connection status and activity. Operating temperature: 0°C to 50°C. Card dimensions: 156.7 x 104.4 mm
