Alphacool Eisball Digital RGB - Plexi (Incl. Eispumpe VPP755 V.3) (13324)

The Alphacool Eisball Digital RGB - Plexi (Incl. VPP Apex PWM Pump) is a spherical 700 ml reservoir with an integrated pump top and Alphacool's VPP Apex PWM pump already pre-installed. Standard Laing D5 pumps cannot be operated upside down in it. The Eisball without a pump is the Eisball D5/VPP Ready.

Properties

• Pump: VPP Apex PWM, pre-installed
• Capacity: 700 ml
• Ports: 3x G1/4 (IN, OUT and fill port)
• Size (LxWxH): 117.51 x 128 x 128 mm
• Lighting: 22 digital RGB LEDs, 5VDC, 4-Pin

Unique Design

Alphacool says the Eisball presents itself with a completely unique design: the first reservoir in the form of a sphere. In its words this makes it an absolute eye-catcher in any water-cooled system, and the shape opens countless new possibilities, especially in the field of modding. Alphacool's examples run from static single color lighting to maybe an R2D2 mod, and it sees no limits to your creativity here. The Eisball has a digital RGB ring that runs once completely around its circumference, on the equator, and 22 LEDs run inside it. Alphacool's claim is that these LEDs illuminate the Eisball perfectly and that beautiful eye-catching illumination is guaranteed. They are addressable and are housed in a chrome-plated ring that Alphacool calls elegant, one which further enhances what it calls the outstanding appearance. A digital RGB controller is of course part of the accessories, which enables you to customize the style and lighting. The Alphacool logo is a simple matte silver and, Alphacool says, fits perfectly to the overall look. It adds that the Eisball is not only a visual delight but is also unique in its functionality and technical implementation.

Versatile Mounting Options

Don't let yourself be limited to a single mounting option, Alphacool says. The included set gives you many: an adhesive mat and 2 different mounting plates put the Eisball on the radiator, the fan slots or a 2.5" SSD slot. Whether it is one or the other, you're covered, and thanks to these options the Eisball can be accommodated in many cases. The proven universal Alphacool pump mounting can also be used, alternatively.

What the loop needs

With the pump pre-installed, the loop needs two fittings, one per port. Alphacool fittings for 16 mm hoses or 13 mm HardTube connections can be screwed in directly (13mm hard tube fittings). For 16 mm HardTube connections an extension or an elbow is required. The third thread is the fill port, which the manual says must be closed with the screw plug, using the screw plug tool. The pump is a PWM version, so its speed is set by the PWM signal from the mainboard or a fan controller. After the pump first runs the water level drops, so top it up.

Notes

• The manual recommends clear coolants from Alphacool's own production (CKC or Eiswasser Crystal, no UV) or pure distilled or osmosis filtered water.

In the box

• 1x Eisball reservoir
• 1x VPP Apex PWM Pump
• 1x screw plug
• 1x screw plug tool
• 1x mounting plate
• 1x velcro mat
• 1x mounting bracket for mounting on fan slots
• 4x decoupler
• 4x M3x5 screws
• 4x M4x5 screws
• 1x Eisball Digital RGB lighting ring
• 1x Digital RGB-Controller
• 1x Digital RGB-Adapter
