KY-024 4-Pin Linear Hall Effect Sensor Module Non-Contact Magnetic Field Detector Analog and Digital Output DC 3.3-5V Adjustable Sensitivity for Motor Speed Counting and Tachometer
- Item #: 9SIVUX4M9C9542
- Mfr. Part #: 241245909949
- KY-024 linear Hall effect sensor module with a 4-pin interface for magnetic field detection without physical contact.
- Detects changes in magnetic fields and provides a non-contact sensing method for speed counting and proximity detection.
- Provides both analog voltage output and digital switching signal for flexible signal monitoring and trigger-based use.
- Built-in onboard potentiometer allows adjustment of magnetic trigger sensitivity to suit different detection needs.
- Operates from a DC 3.3V to 5V power supply for use in compatible low-voltage electronic circuits.
- Features quick-response magnetic sensing for rotating speed measurement, tachometer construction, and motor RPM testing.
- Supports magnetic proximity detection and position sensing applications where contact-free detection is required.
- Specified operating temperature range is -10 to 60.
+
+
Overview
Specs
Reviews
Product Description:
KY-024 linear Hall effect sensor module for non-contact magnetic field detection. It is designed for speed counting, tachometer applications, motor RPM testing, magnetic proximity detection, and position sensing.
Core Selling Points:
Detects changes in magnetic field strength without physical contact. Provides both analog voltage output and digital switching signal for flexible signal monitoring. The onboard potentiometer allows adjustment of magnetic trigger sensitivity. Fast response and stable performance support rotating-speed measurement and magnetic detection projects.
Technical Specifications:
Model: KY-024. Type: Linear Hall Effect Magnetic Sensor. Interface: 4-pin. Power supply: DC 3.3V-5V. Output: Analog signal plus digital switch signal. Adjustment: Onboard potentiometer for sensitivity. Operating temperature: -10 to 60°C.
Before Purchase:
Confirm that your control board supports a 4-pin sensor connection, DC 3.3V-5V power input, and analog or digital signal input as needed. This module is intended for magnetic field sensing and requires a magnetic source for detection.
