WH118 470K Ohm Variable Resistors Single Turn Rotary Carbon Film Potentiometer w Knobs

• Product Name: Carbon Film Potentiometer
• Model: WH118
• Material: Carbon film Metal
• Resistance Value: 470K ohm
• Tolerance: +/-20%
• Turn Number: Single Turn
• Terminals Number: 4
• Features: Round Shaft
• Total Size: 28.5mm x 34.5mm/1.12 x 1.36 inch (D * H)
• Screw Thread Dia.: 9.89mm/0.39 inch
• Shaft Diameter: 6mm / 0.24 inch
• Shaft Length(do not include the Screw Thread parts): 9mm / 0.35 inch
• Shaft Total Length 20mm/0.79 inch
• Package Content: 1 x Carbon Film Potentiometer /1x Knobs
• Knobs Size: 24.6x19.8mm / 0.97x0.78 inch (D * H)
• Knobs Colors: Black
• Features: 470K ohm, 4 Terminals, Single Linear, Suits Most Standard Knobs.this item do not include Knobs)
• Top adjustment type and knurled shaft for easy operate in daily use.
• Main used to control electrical devices such as volume controls on audio equipment.
• Knurled shaft with split design for push-on knob.
