PARKER H1E Coupler Plug,Steel,FNPT,1/4 In. Pipe

The PARKER - H1E is a steel quick connect hose coupling intended for use with pneumatic (compressed air) systems. It features a 3/8-inch industrial interchange plug with a 1/4-inch female NPT hose fitting, supporting quick-connect coupling for connection and disconnection without a hand tool (per design). The coupling is intended to connect compressed-air components to form a sealed connection within specified operating conditions. It is rated for operation within -40°F to 250°F and is rated for a maximum working pressure of 300 psi. Its trivalent chrome finish has trivalent chrome plating on visible surfaces.

Key Features:

• - Material: Steel construction.
• - Hose Fitting Size and Gender: 1/4 in female NPT connection.
• - Connection Type: Female NPT thread with 1/4"-18 thread size.
• - Max. Flow Rate: 1,415.84 liters per minute.
• - Max. Working Pressure: 300 psi at 70°F.
• - Temperature Range: -40°F to 250°F.
• - Overall Length: 1.56 in (1 9/16 in).
• - Max. Outside Diameter: 11/16 in.
• - Includes Valve: No valve included.
• - Interchange Type: Industrial standard plug.
• - Barbed: No barbed hose tail.
