ZORO SELECT 4307001522 2 in 316 Stainless Steel Socket Weld Half Coupling,

The ZORO SELECT - 4307001522 is a stainless steel half coupling designed to join or reduce branch connections in piping systems where a full-length coupling is unnecessary or space is limited. Constructed from 316 stainless steel, this half coupling features a socket weld connection on one end and a female NPT threaded connection on the other, each with a nominal pipe size of 2 inches. It is rated for Class 3000 pressure rating and has a maximum internal pressure rated at 3,000 psi at 100°F; maximum steam pressure rated at 2,810 psi at 350°F. The fitting meets the ASME B1.20.1 NPT thread standard, ASTM A182 material specification, and ASME B16.11 dimensional standard. Key Features:

• - Material: 316 stainless steel.
• - Type: Half coupling with one end shortened to engage a single pipe.
• - Connection types: Female NPT threaded connection on Side A, socket weld (plain) connection on Side B.
• - Nominal pipe size: 2 inches on both ends.
• - Pressure class: Class 3000, with maximum pressure ratings of 3,000 psi at 100°F (internal) and 2,810 psi at 350°F (steam).
• - Outside diameter: 3 inches.
• - Overall length: 1 5/8 inches.
• - Thread and material standards: ASME B1.20.1 for threads; ASTM A182 for materials; ASME B16.11 for dimensions.
• - Includes no pre-applied thread sealant or sealing components.
