Memory: Standard: 8 MB SDRAM (3 MB available to user); 4 MB Flash (1.5 MB available to user)
Optional: 64 MB Flash (68 MB total) with real time clock (65.5 MB available to user)
Fonts Included: 16 resident expandable ZPL II bitmap fonts
One resident scalable ZPL font
Five resident expandable EPL2 bitmap fonts
Supports user-defined fonts and graphics - including customer logos
Barcode Type: Linear Codabar
Code 11
Code 128
Code 128 with subsets A/B/C
Code 39
Code 93
EAN-13
EAN-14
EAN-8
EAN-8 and EAN-13 with 2 or 5 digit extensions
German Post Code
Industrial 2-of-5
Interleaved 2-of-5
Japanese Postnet
Logmars
MSI
MSI-3
Postnet
RSS (reduced space symbology)
Standard 2-of-5
UCC/EAN-128
UPC and EAN 2 or 5 digit extensions
UPC-A
UPC-A and UPC-E with 2 or 5 digit extensions
UPC-A and UPC-E with EAN 2 or 5 digit extensions
UPC-E
2...
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered -in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate? Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – ...
Fonts Included: 16 resident expandable ZPL II bitmap fonts
One resident scalable ZPL font
Five resident expandable EPL2 bitmap fonts
Supports user-defined fonts and graphics - including customer logos
Barcode Type: Linear Codabar
Code 11
Code 128
Code 128 with subsets A/B/C
Code 39
Code 93
EAN-13
EAN-14
EAN-8 and EAN-13 with 2 or 5 digit extensions
EAN-8
German Post Code
Industrial 2-of-5
Interleaved 2-of-5
Japanese Postnet
Logmars
MSI
MSI-3
Plessey
Postnet
RSS (reduced space symbology)
Standard 2-of-5
UCC/EAN-128
UPC and EAN 2 or 5 digit extensions
UPC-A
UPC-A and UPC-E with 2 or 5 digit extensions
UPC-A and UPC-E with EAN 2 or 5 digit extensions
UPC-E
2-dimensional Aztec
Codablock
Code 49
Data Matrix
MacroPDF417
MaxiCode
MicroPDF417
PDF417
QR Code
RSS / GS1 DataBar famil...
Ribbon Characteristics: Outside diameter: 3.20" / 81.30 mm on a 1.00" / 25.00 mm I.D. core
Ratio: 3:1 media-roll-to-ribbon ratio for ZT230
Width: 1.57" / 40.00 mm to 4.33" / 110.00 mm
Media Type: Continuous, die-cut, notch, black mark
Media sizes supported: Maximum label and liner width: 4.50" / 114.00 mm
Media Width: 0.75" / 19.40 mm to 4.50" / 114.00 mm
Maximum Media Roll Size:
8.00" (203.00 mm) O.D. on a 3.00" (76.00 mm) I.D. core
6.00" (152.00 mm) O.D. on a 1.00" (25.00 mm) I.D. core
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered -in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate? Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – ...
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered -in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate? Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – ...
Barcode Type: Codabar, Code 128, Code 128-A, Code 128-C, Code 128-B, Code 11, Code 39, Code 93, EAN-13, EAN-14, EAN-8, EAN-13 With 2 or 5 Digit Extension, EAN-8 With 2 or 5 Digit Extension, German Post Code, Industrial 2 of 5, Interleaved 2 of 5, Japan Postal, LOGMARS, MSI-3, MSI, Plessey, POSTNET, RSS, Standard 2 of 5, UCC/EAN 128, UPC 2 or 5 Digit Extension, EAN With 2 or 5 Digit Extension, UPC-A, UPC-E, UPC-A with 2 or 5 Digit Extension, UPC-E with 2 or 5 Digit Extension, Aztec Code, Codablock, Code 49, Data Matrix, Macro PDF-417, Maxi Code, Micro PDF-417, PDF-417, QR Code, GS1 DataBar
Media Type: Black Bar, Black Mark, Continuous Label, Continuous Receipt, Die-cut Label, Fanfold, Gap, Perforated Label, Notched, Receipt, Roll Fed, Tag, Tag Stock, Direct Thermal Label, Wristband
