Specifications: Drive Connectors: 1 - M.2 (NGFF) Receptacle
Host Connectors: 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Maximum Data Transfer Rate: 6 Gbps
Type and Rate: SATA III (6 Gbps)
Features: Open-frame steel mounting bracket
Supports 7mm or larger 2.5" SATA bays
Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
2.5in SATA form factor housing
Supports full length M.2 NGFF (Next Generation Form Factor) SSD Solid State Drives (2230, 2242, 2260, 2280)
Mobile Rack Drives Support: Multi 3.5" Drives to Multi 5.25" Bays
Protection Case: Multiple Drives
Specifications: Drive Fit: 2 x 2.5" IDE / SATA SSD / HDD
Support Drive Height: 7.00mm - 9.50mm
Device Fit: 1 x 3.5" Hard Drive Bay
Structure: Plastic
Dimension (L x W x H): 5.30" x 4.17" x 1.00"
Weight: 0.13 lb.
Features: Durable one-piece design
Anti-Vibration design for improved reliability
Fits 2 x 2.5" SATA / IDE SSD / HDD into one 3.5" drive bay
Compatible with 2.5" SSD & HDD with 7mm to 9.5mm drive height
Quick release eject mechanism for hassle free tool-less drive installation
Universally designed screw placement for maximum compatibility
60 screw holes provide maximum flexibility of installation
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III/SAS
Specifications: Product Type: Drive Enclosure
Number of Total Expansion Bays: 2
Number of 5.25" Bays: No
Number of 3.5" Bays: No
Number of 2.5" Bays: 2
Number of 2.5"/3.5" Bays: No
Number of 1.8" Bays: No
Drive Interface: Serial ATA, SAS
Form Factor: Internal
Compatible Drive Bay Width: 3.5"
Height: 1.0"
Width: 4.0"
Depth: 6.1"
Mobile Rack Drives Support: 16x 2.5" Drives to 2x 5.25" Bay
Mobile Rack Interface: SATA I/II/III/SAS
Protection Case: Multiple Drives
Compatible Products: 2.5"
Specifications: Host Interface: 4 x miniSAS HD (SFF-8643)
Drive Fit: 16 x 2.5" SAS/SATA SSD & HDD (7mm drive height)
Device Fit: 2 x external 5.25" bay
Transfer Rate: SATA up to 6 Gb/sec. (depending on hard drive speed), SAS up to 12Gbps (Single Channel)
Power Input: 4 x 15pin SATA power port
Insert& Extract connection Via: Direct SATA hard drive connection
Structure: Metal
Drive Cooling:
Single 80mm rear cooling fan
Metal heat dispersion
Power Indicator: Solid green LED
HDD Access Indicator: Flashing green LED
Dimension (W X H X D): 146 x 84 x 157.5mm
Features: Rugged heavy duty full-metal constructio...
Mobile Rack Drives Support: 3 x 3.5" Drives to 2 x 5.25" Bays
Mobile Rack Interface: SATA I/II/III/SAS
Protection Case: Multiple Drives
Compatible Products: 3.5"
Specifications: Support Drive Size: 3.5" HDD
Compatible Drive Type: SATA / SAS
Number of Drives: 3
Drive Bay: 2 x external 5.25" drive bay
Host Interface: 3 x SATA 7pin
Power Input: 2 x 15 pin SATA power connector
Transfer Rate: Up to 6Gbps (Depending on hard drive speed)
Support HDD Capacity: No Limitation
Drive Cooling: 80mm cooling fan & Metal heat dispersion
Structure / Material: Metal and ABS plastic
Support Hot-Swap: Yes
Compliance: CE, RoHS, REACH
Drive Activity LED Indication: Drive power: solid blue; HDD access: flashing blue
Features: Fits 3 x 3.5-inch SAS/SATA HDDs into 2 x 5.25-inch external ODD/de...
Mobile Rack Drives Support: 4 x 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III
Protection Case: Multiple Drives
Compatible Products: 2.5"
Specifications: Host Interface: 4 x 7pin SATA
Drive Fit: 4 x 2.5" SATA I / II / III SSD or hard drive
Device Fit: Single external half height 5.25" bay
Transfer Rate: Up to 6 Gb/sec. (depending on hard drive speed)
Power Input: 1 x 15pin SATA power port
Insert& Extract connection Via: Direct SATA hard drive connection
Structure: Metal
Drive Cooling: Singlel 40mm rear cooling fan + fan power switch, Metal heat dispersion
Power Indicator: Solid green LED
HDD Access Indicator: Flashing green LED
Compatible Products: Single 2.5" SAS/SATA HDD/SSD (SAS host required for SAS drives)
Specifications: Device Interface :
Single 22pin SATA (Support SAS single channel)
Drive Fit :
Single 2.5" SAS/SATA HDD/SSD (SAS host required for SAS drives)
Compatible Drive Heights :
7mm to 9.5mm
Host Interface :
Single 7pin SATA
Device Fit :
Slim ODD or slim FDD bay
Transfer Rate :
Up to 6 Gb/sec. (depending on hard drive speed)
Power Input :
Mini 4-pin power wafer
Insert& Extract connection Via :
Direct SAS/SATA hard drive connection
Structure :
Full metal
Drive Cooling :
Metal heat dispersion
Power Indicator :
Solid green LED
HDD Access Indicator :
Flashing green LED
Drive Security :
Eagle-hook locking mechanisms
Dimension ...
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III/SAS
Protection Case: Multiple Drives
Specifications: Color: Matt Black
Host Interface: 7 pin SATA x 4
Drive Fit: 2.5" SAS or SATA I /II/III HDD / SSD x 4
Drive Bay: 5.25" Bay x 1
Transfer Rate: Up to 6 Gb/sec. (depending on hard drive speed)
Insert& Extract conection Via: 15 pin direct hard drive connection
Structure: SECC
Drive Cooling: 40mm rear cooling fan x 2 & metal heat dispersion
LED Indication: Device Power & Drive Activity
LED Display Color: Green - Device Power ; Amber - Drive Activity
Dimension (L x W x H): 6.70" x 5.75" x 1.63"
Weight: 1.77 lbs.
Features: Fits 4 x 2.5" SATA I / II / III and SAS HDD/SSD.
Sup...
Mobile Rack Drives Support: 4 x NVMe U.2 SSD in a Single 5.25" Device Bay
Mobile Rack Interface: 4 x miniSAS HD (SFF-8643)
Protection Case: Multiple Drives
Compatible Products: 2.5"
Specifications: Support Drive Size: 4 x 2.5" U.2 SSD / HDD
Compatible Drive Type: U.2 NVMe
Number of Drives: 4
Max Drive Height: 15mm
Drive Bay: 1 x external 5.25" drive bay
Host Interface: 4 x miniSAS HD (SFF-8643)
Power Input: 2 x 15 pin SATA power connector
Transfer Rate: Up to 32 Gbps
Support HDD Capacity: No Limitation
Drive Cooling: 2 x 40mm fan
Structure / Material: Full Metal
Support Hot-Swap: Yes
Mobile Rack Drives Support: 1 x 2.5" Drive to PCI Slot
Mobile Rack Interface: SATA I/II/III
Specifications: Max. HD Capacity: 500 GB
Enclosure Type: Aluminum and Steel
Compatible Drives: 2.5" SATA
Host Connectors: 1 - 7 pin SATA DATA Male
Host Connectors: 1 - 15 pin SATA Power Male
Drive Connectors: 1 - 7 pin SATA DATA Female
Drive Connectors: 1 - 15 pin SATA Power Female
Features: Completely OS Independent
Door mounted LED indicator for Power and HD Activity, allows you to visually observe enclosure status
Driver free support and tool-less design for HD installation
Latchable door
Supports almost all 2.5in hard drives; 12mm high drives not supported
Supports hot swap hard drive installations
Supports maximum data transfer rates up to 3.0 Gbps (using SATA II drive)
Supports SATA II ha...
Specifications: Drive Connectors: 1 x SATA Data & Power Combo (7+15 pin)
Host Connectors: 1 x SATA Data & Power Combo (7+15 pin)
Dimensions: 1.40" x 4.00" x 5.70"
Weight: 9.20 oz.
Features: Supports 2.5" SSD/HDD up to 12.5mm in height
Standard 3.5" HDD mounting points
Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
Tool-less installation
Package Contents: 1 x 2.5" to 3.5" SATA HDD/SSD Enclosure
1 x Screw kit
1 x Install Guide
Specifications: Compatible Drive Types (Type and Rate): SAS & SATA
Drive Installation: Removable
Drive Size: 2.5in
Fan Bearing Type: Sleeve Bearing
Fan(s): Yes
Fans: 2 - 40 mm
Interface:
SATA
SAS
Key Lock: Yes
Number of 2.5 inch bays: 4
Number of Drives: 4
Supported Drive Height(s):
5mm
9.5mm
12.5mm
15mm
Hot Swap Capability: Yes
Insertion Rating: 50,000
Max Drive Capacity: Tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate : 6 Gbps
MTBF: 30,000
Noise Level: 20 dBA
Port Multiplier: No
Type and Rate: SATA III (6 Gbps)
Drive Connectors: 4 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors: 4 - SATA (7 pin; Data) Receptacle
Other Interfa...
Specifications: Color: Black
Drive Connectors: 1 - SFF-8482 (29 pin; Data & Power; Internal SAS) Receptacle
Drive Installation: Removable
Drive Size: 2.5in
Drive Type: SAS & SATA
Enclosure Type: Plastic
Fan(s): No
Host Connectors: 1 - SATA Data & Power Combo (7+15 pin) Plug
Key Lock: No
Max Drive Height: 0.59 in [15 mm]
Number of 2.5 inch bays: 1
Number of Drives: 1
Features: Trayless design: hard drives are not mounted into separate trays/enclosures
Supports 2.5" form factor hard drives (HDD) and solid state drives (SSD) up to 15mm in height
Standard 3.5" hard drive mounting points along sides and bottom
Power indicator LED
Lightweight plastic construction with air vents
Plug and Play and hot swap compatible.
Turn Virtually any 2.5in SA...
Mobile Rack Drives Support: 1 x 2.5" Drive to 3.5" Bay
Mobile Rack Interface: SATA I/II/III/SAS
Protection Case: Single Drive
Compatible Products: 2.5"
Specifications: Compatible Drive Types: SAS & SATA
Drive Installation: Removable
Drive Size: 2.5in & 3.5in
Fan(s): No
Interface : SATA / SAS
Number of 2.5 inch bays: 1
Number of Drives: 1
Supported Drive Height(s): 7mm / 9.5mm / 12.5mm / 15mm
4Kn Support: Yes
Hot Swap Capability: Yes
S.M.A.R.T. Support: Yes
TRIM Support: Yes
Type and Rate: SATA/SAS 6 Gbps
Connectors:
Drive Connectors: 1 x SFF-8482 (29 pin, Data & Power, Internal SAS) Receptacle
Host Connectors: 1 x 22 pin SATA / SAS Data + Power (7 + 15 pin) Receptacle
Mobile Rack Drives Support: 1 x 2.5" Drive to 3.5" Bay
Mobile Rack Interface: SATA I/II/III
Protection Case: Single Drive
Specifications: Host Interface : Single 7pin SATA
Drive Fit : Single 2.5" SATA I/ II/ III HDD/ SSD (7-15mm Height Drive)
Drive Bay : 3.5" floppy drive bay
Transfer Rate : Up to 6 Gb/sec. (depending on hard drive speed)
Power Input : Single 15pin SATA power port
Insert& Extract connection Via : Direct SATA hard drive connection
Structure : Full Metal
Drive Cooling : Metal heat dispersion
LED Indication : Device Power & Drive Activity
LED Color : Green : Device Power ; Amber : Drive Activity
Dimension (L x W x H) : 5.32" x 4.00" x 1.01"
Weight : 0.88 lbs
Specifications: Device Interface:
2 x 22 pin SATA (Support SAS single channel)
Drive Fit:
2 x 2.5" SAS/SATA HDD/ SSD
Compatible Drive Heights:
7mm to 9.5mm
Host Interface:
2 x 7 pin SATA
Device Fit:
3.5" front device bay (floppy bay)
Transfer Rate:
Up to 6 Gb/sec. (depending on hard drive speed)
Power Input:
Single 15 pin SATA power port
Insert& Extract connection Via:
Direct SAS/SATA hard drive connection
Structure:
Full metal
Drive Cooling:
Metal heat dispersion
Power Indicator:
Solid green LED
HDD Access Indicator:
Flashing amber LED
Drive Security:
2 segment key lock + thumb screw lock
Dimension (L x...
Mobile Rack Drives Support: Multi 2.5" Drives to 3.5" Bay
Mobile Rack Interface: SATA I/II/III
Protection Case: Multiple Drives
Specifications: Color: Matt Black
Host Interface: 7 pin SATA x 2
Drive Fit: 2.5" SATA I/II/III SSD or HDD (9.5mm thickness)
Drive Bay: 3.5" floppy drive bay
Transfer Rate: Up to 6 Gb/sec. (depending on hard drive speed)
Insert& Extract connection Via: Direct hard drive SATA connection
Structure: Full Metal
Device Power: 15 pin SATA power x 1
Drive Cooling: Airflow vents with metal heat dissipation
Power Indicator: Solid Green LED (Power On)
HDD Access Indicator: Flashing Amber LED
Dimension (L x W x H): 133 x 101.2 x 25.4mm
Features: Fits 2 x 7mm to 9.5mm 2.5" SATA drives/ SSD's in a 3.5" ...
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III/SAS
Compatible Products: 4 x 2.5" SAS or SATA I/ II/ III HDD/ SSD
Specifications: Host Interface : 4 x 7pin SATA
Drive Bay : Single 5.25" half height device bay
Transfer Rate : Up to 6 Gb/sec. (depending on hard drive speed)
Power Input : 2 x 4pin Molex power port
Insert& Extract connection Via : Direct SAS/ SATA hard drive connection
Structure : Aluminum & SECC
Drive Cooling : 40mm rear cooling fan x 2 & metal heat dispersion
LED Indication : Device Power & Drive Activity
LED Color : Green : Device Power ; Amber : Drive Activity
Drive Security : Custom Steel Lock
Dimension (L x W x H) : 6.70" x 5.75" x 1.63"
Weight : 1.98 lbs...
Features: The 3.5 inch to 5.25 inch adapter brackets allow 3.5 inch drives hard drives to be mounted in standard 5.25 inch drive bays. It works with IDE, SCSI, or SCA drives.
It works with IDE, SCSI, or SCA drives.
Durable all metal construction for mounting any type of 3.5in device into a 5.25in bay.
