Specifications: LCD Size: = 24"
Weight Capacity: <= 25 lbs(= 11.3 kg)
Tilt: 180°
Pan: 360°
Rotation: 360° P/L
VESA: MIS-D
Includes 200 wall mount pivot, wall mount bracket, 2 extensions, VESA mounting screws
If mounting a laptop, also order the LX Notebook Tray (50-193-200)
Weight Capacity: 25 lbs (11.3 kg)
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Extends up to 23.8" (60.5 cm) from the wall and retracts to within 5.8" (14.8 cm), excluding depth of monitor
Durable, easy-to-clean powder-coated painted steel exterior
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
Specifications: Description: Steel Stud Wall Mounting Kit
Includes Wall Plate, six (6) screws, six (6) anchors
Screw size = 1/4-20 x 1-1/2"
Compatible Ergotron Mounts: Neo-Flex HD Wall Mounts, LX Wall Mount Arms, 100 Series Pivots, 200 Series Wall Mounts, 400 Series Wall Mount Arms
Weight Capacity: 50 lbs (22.7 kg)
UL compliant: Tested to four times its maximum weight capacity per UL 1678 Specification (do not exceed 50 lbs/22.7 kg in actual use)
Specifications: Large sturdy platform measures 18" x 10" (W x D)
Features: Clean modern design raises your monitor 5.25 inch to a comfortable and ergonomically correct viewing height to reduce neck strain
Great for monitors, laptops, printers, TVs, gaming consoles, DVD players, stereos upto 50 lbs/22 kg
Unique design allows for keyboard to slide underneath platform, keeping it out of the way when not
Specifications: Description: DS100 Crossbar Extender, Long (black)
Includes: Long Extenders, Center Display Bracket, Attachment hardware
Display: Maximum physical outside width of display = 24.5" (62 cm). This is slightly more than typical display with a 26" screen.
Weight Capacity: 31 lbs (14 kg) per monitor
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: Description: Spacer kit for mounting to 75 x 75 mm recessed monitors (black)
Includes (1) spacer and (4) Phillips pan head M4 x 25 mm screws
Specifications: LCD Size: <= 24"
Weight Capacity: <= 25 lbs.
Tilt: 180 degree
Pan: 180 degree
Rotation: 360 degree P/L
Certifications & Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Features: This pivot provides full tilt and panning capability and saves space with its compact design. Easily position the angle of your monitor for maximum comfort and productivity
Specifications: Weight Capacity: 23 lbs
LCD Size: 24"
Tilt: 180º
Pan: 180º
Rotation: 360º
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. To increase support, a separately-ordered Wall Plate or Wall Track accessory is recommended
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Weight: 3 lbs (1.4 kg)
Specifications: LCD Size: <= 22"
Weight Capacity: 13 lbs (5.9 kg) per mount, 26 lbs (11.8 kg) total. Note: Monitors must be equal in weight or ±1 pound (.45 kg)
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Install display mounts on the bow at +2.5° or -2.5° angle to optimize viewing conditions
Monitors are installed with 8° inward off-set angle, creating a 16° viewing parabola for better sight lines
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Durable, easy-to-clean powder-coated painted steel exterior
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
Includes wall mount bracket, 2 extensions, crossbar and 2 sliding LCD mounts, VESA mounting screws
Specifications: LCD Size: <= 24"
Lift: 13"(33 cm)
Tilt : 85°
Pan: 360°
Rotation: 360° P/L
VESA: MIS-D
Versatile: Use with a notebook and LCD or with two LCDs
Weight Capacity: Maximum individual LCD weight = 7 to 20 lbs (3.1 to 9.1 kg); notebook weight range = 2.5–12 lbs (1.1–5.4 kg); maximum combined weight = 40 lbs (18.1 kg). Monitor depth may affect weight capacity
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Dimensions: 19.25" x 15.25" x 9" (487 x 387 x 229 mm)
Shipping Weight: 15.75 lbs (7.18 kg)
Specifications: Includes stand, CPU strap, buckle cover, VESA monitor mounting kit, cable ties
* Weight Capacity: 6 - 16 lbs. for display; total stand capacity = 37 lbs for combined weight of display, CPU, keyboard and mouse
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Meets tip test requirements of UL Specification 1678
Compatible with most 15" - 24" displays, and most small or ultra small form factor CPUs, notebook computers, and gaming consoles
Maximum CPU size = 14" H x 4" D (36 x 10 cm); minimum CPU size = 7" H x 1.8" D (18 x 4.6 cm). The CPU should be centered on the stand
Motion may be restricted when using 22" - 24" monitors in portrait mode
Removal of lock screw allows portrait to landscape rotation
Mounting Option: Two M4 threaded screw inserts are located at the bottom of ...
Specifications: Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Maximum outside width of display: 21.25" (Displays are 2" (5 cm) thick)
Typically horizontal dimension: 22"
Features: Simple installation and effortless operation
Accommodates an upgrade to your computer system, allowing you to reuse your WorkFit in a different hardware configuration
