Connectivity: Rally Table Hub
Single CAT6A cable connection to Rally Display Hub (16.4 ft / 5m cable included, supports customer-supplied cables up to 164 ft (50 m)
Hub 5 m cable included, supports customer-supplied cables up to 50 m
Active speaker detection: analyzes audio from up to 7 Mic Pods and 56 beams every 8 ms
12 Pin connector for Rally Mic Pod
HDMI Type A passthrough to Display Hub (x2)
USB Type C
USB Type A (reserved for future capability)
USB Type B (connects to meeting room computer)
RJ45 (reserved for future capability)
Power input
Rally Display Hub
HDMI Type A: (x2) (connects to displays)
USB C (connects to Rally Camera)
USB Type B (connects to meeting room computer)
RJ45: connects to Table Hub
Mini XLR: x2
Powers one or two Rally Speaker...
Additional Features: Echo Cancellation
Tail time: 60 ms x 3
Noise Cancellation
Dynamic noise cancellation
Keypad
Alphanumeric standard keypad
Loudspeaker
Volume: 90dBspl A weighted @ 1 ft
Bandwidth: 200 Hz–3.3 kHz
Record Output
Connector: 2.5 mm mono audio jack
Impedance: <1000 ohms
Bandwidth: 200 Hz–3.3 kHz
Dynamic range: 60 dB
THD <.01%
Certifications
FCC part 15 Class A
FCC part 68
UL Certified
Environmental
Operating temperature: 32–118° F (0–48° C)
Storage temperature: 41–158° F (5–70° C)
Operating humidity: 15 to 80%
Storage humidity: 10 to 90%
Speakerphone: Yes
Power: Base unit:
Auto-adjusting power module;
100-240 VAC; 50/60 Hz
Connections: Analog PBX or PSTN line
RJ-11C, -12 dBm nominal
