Specification: GENERAL SPECIFICATIONS
Integrated ultrasonic speaker
Integrated PIR Motion Sensor
Integrated accelerometer
Integrated ambient light sensor
100 mm x 100 mm VESA FDMI
Internal cable retention and strain relief system
Power: Cable length: 3.94 ft / 1.2 m
Capacity: 3640mAh
Battery Life: 40hrs when connected via Bluetooth at 50% speaker volume
Charging speed: 3.5hrs from 0%~100%
Digital Video Capture Resolution: Graphics Modes (Live): 4K UHD
Maximum Video Resolution (Live): 3840 x 2160
Maximum Frame Rate: 60 fps
Specification: Interfaces/Ports
HDMI In
HDMI Out
Network (RJ-45)
USB
Number of Network (RJ-45) Ports: 1
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
Technical Information
Features: Noise Reduction
Room Size: Medium
Camera: Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical
Additional Features: Complete room solution enables secure wireless AirMedia presentation from laptops, smartphones, tablet devices, and AirMedia Connect Adapters
Enables smart automation via intelligent display control, personal device control, occupancy detection, and integration into a broader connected ecosystem
Enterprise-grade security and content encryption protects privacy and ensures compliance with IT policies
XiO Cloud® service support for remote provisioning and management
Integrates with Appspace® digital signage software platform for content display
Supports content sharing of four simultaneous sources for multi-user collaboration with AirMedia Canvas.
Wireless conferencing and presentation allows for collaboration with in-room and remote participants (feature enablement required, coming soon)
Integrates with optional Kaptivo Whiteboard Device to displa...
Connectivity: Connection Method: USB-C Cable, Bluetooth, 3.5mm Jack
USB Cable: USB-C to C, 1m
C-A Adapter
Bluetooth Version: Bluetooth 5.3
Bluetooth Range: Up to 20m (66ft)
Supported Bluetooth Profiles: A2DP, AVRCP, HFR Profiles, SBC codec
Camera: Digital Pan: ±48° at 4x zoom
Digital Tilt: ±32° at 4x zoom
Zoom: 4X HD digital zoom
Diagonal Field of View: 120°
Horizontal Field of View: 113°
Vertical Field of View: 80°
Resolution: 4k
Camera: Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical
Camera: Number of cameras: 3
Type of camera: Panoramic multi-camera array
Camera resolution: 13 megapixels
Zoom: Up to 6x lossless digital zoom
Field of view: Horizontal: 180°, Vertical: 54°
Resolution: Panoramic-4K: 3840 x 1080 @ 30fps
Intelligent Zoom: Yes
Virtual Director: Yes
Vivid HDR: Yes
Camera: 12MP camera
30 frames per second
1/2.3’’ CMOS
5x digital zoom
f/2.5 aperture
120° horizontal field of view
95° vertical field of view
Auto framing (face detect)
Speaker tracking
Auto brightness and white balance
Fixed focus lens
Automatic rotation of the image when the video bar unit is mounted upside down
Frames camera mode for individual participant framing
Digital Video Capture Resolution: Video Standards:
H.263, H.264, AV1
Video Inputs:
1x HDMI input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
1x USB-C input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
Consumer Electronics Control (CEC) 2.0
Video Outputs:
2x HDMI outputs supporting formats up to 3840 x 2160 at 60 fps
Live video resolutions (encode and decod...
