Specifications: Description: 8 Digital Inputs and 8 Digital Outputs
Digital Inputs: 8
Logic Level 0: -30.0V to +1.0V
Logic Level 1: +2.0V to +30V
Latched Inputs: Triggered by user programmable positive or negative edges, stays true until acknowledged
Counter Inputs: User progammable- counts positive or negative transitions up to 100Hz
Watchdog: Active high/low, Pulsed high/low
Digital Outputs: 8
Digital Output Type: Open drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min
Maximum Output Load Voltage: 30 VDC
Maximum Output Current Sink: 0.85A per channel
Serial Gateway: RS485 NuDam/ADAM compatible gateway
Number of Ports: 1
Network Port Type: RJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX)
Network Protocols: ICMP, IP, TCP, DHCP, HTTP
Protection: 1500V M...
Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.]
Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.]
Standards: IEEE 802.3
Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes
Status LEDs:
PWR (Power): (below RJ-45)
ON = Lit for normal operation
FX-Link/Act (Fiber Link/Activity):
(Upper Left on RJ-45)
ON = Link; Flashing = Activity
TX-Link/Act (Copper Link/Activity):
(Upper Right on RJ-45)
ON = Link; Flashing = Activity
Power
Consumption: 3.15 Watts
Sources: Unit accepts 5 VDC to 28 VDC
Wall Mount AC adapter: 12 VDC 400mA
Environment
Storage: -15 to +65 °C
Operating: 0°C to 50°C
Altitude: 0 – 10,000 feet
Humidity: 5% to 95% (non-condensing)
Compliance
Safety: Wall Mount Power Supply, UL Listed,
C-UL Listed ...
Specifications: Interface:
"Data" Input Port: 1 x RJ-45 STP
"PoE (Data+Power)" Output Port: 1 x RJ-45 STP
Input power terminal block: 1
LED Indicator:
System: Power 1, Power 2, Fault (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
10Base-T: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000Mbps
Dimension: 1.26" x 5.31" x 3.46"
Weight: 1.05 lbs.
Unit Input Voltage: 24 - 48V DC; 24V AC
Power Consumption: 30 watts max.
Number of device can be powered: 1
Installation: DIN rail kit and wall mount ear
Alarm:
Provides one relay output for power failure,
Alarm relay current carry ability: 3A at DC 30V
Enclosure: IP30 slim type metal case
Power over Ethernet
PoE Standard: IEEE 802.3at High ...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Multi-mode
Fiber Optic Cable Wavelength:
0 mil
Maximum Distance Supported:
0.55 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
Co...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Single-mode
Fiber Optic Cable Wavelength:
0.1 mil
Maximum Distance Supported:
40 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
...
Specifications: Enclosure Type: Rubber
Included in Package: 10 - dust caps
Features: Dust covers insert easily into unused SFP LC ports, to protect your network switches from dust and contaminants
Made of durable rubber
Work with SFP / SFP+ LC ports in optical networking equipment
Easy to insert and remove
Specifications: Cable Type: SFP+
Cable Length: 9.84 ft.
Connector on First End: 1 x SFP+ Network
Connector on Second End: 1 x SFP+ Network
Data Transfer Rate: 1.25 GB/s
Compatibility: Aruba 8320 Switch Series
Specifications: Hardware Version: 4
Interface:
Data Input Ports: 24 x RJ45
Data + Power Output Ports: 24 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000 Mbps
LED:
System:
1 x SYS PWR (Green)
1 x PoE1 Fail (Red)
1 x PoE2 Fail (Red)
1 x Fan1 Fail (Red)
1 x Fan2 Fail (Red)
Per PoE Port: 1 x PoE-in-Use (Green)
2 x Management port: 1000 (Green), 10/100 (Orange)
Network Cable:
10BASE-T: 4-pair UTP Cat5 up to 100m (328 ft.)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328 ft.)
1000BASE-T: 4-pair UTP Cat5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Power Requirements: 100-240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts max.
Cooling: 3 x Fan
PoE Power Supply Type: Mid-span
PoE Power Output: Per port DC 50-57V 30.8 / 15.4 watts
Power Pin Assignment...
Specifications: Interface
LAN: 1 x RJ45 STP, "Data" Input Port
PoE: 1 x RJ45 STP, "Data + Power" Output Port
AC Connector: 1 x AC input power socket, IEC-320 C6
Network Cable
Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
802.3af/at PoE (15W/30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
LED Indicator
System: Power x 1 (green)
PoE Port: Active, PoE ready/in-use x 1 (green)
Data Rate: 10/100/1000Mbps
Unit Output Voltage: DC 56V, 1.08A
Power Requirements: 100 - 240V AC at 50/60Hz, 1.5A max.
Power Consumption: 60 watts max.
Temperature
0 - 50 degrees Celsius (Operating)
-10 - 70 degrees Celsius (Storage)
Humidity: 5 - 95%, relative humidity, non-condensing
PoE Standard:
Ultra PoE over 4-pair UTP cable
IEEE 802.3at Power over Ethernet Plus End-span/Mid-span PSE
PoE Power Supply Type: End-span + Mid-span ...
