Specifications: No. of Ports: 24
Pass Through Data Rates: 6500G: 10/100/1000 Mpbs
Power over Ethernet Output
Pin Assignment and Polarity: 4/5 (+), 7/8 (–)
Output Power Voltage: 52Vdc
User Port Power: 15.4Watts
Aggregate Power: 400Watts
Input Power Requirements
AC Input Voltage: 90 to 264 Vac
AC Input Current:
100W 2A at 110 Vac, 1A at 220 Vac
200W 4A at 110 Vac, 2A at 220 Vac
400W 5.5A at 110 Vac, 2.75A at 220 Vac
AC Frequency: 47 to 63 Hz
Dimensions: 17.3 in. x 10.8 in. x 1.75 in or 1U
Weight: 8.80 lbs. (4kg)
Management: PowerView Pro included
Indicators
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green)
Connectors: Shielded RJ-45, EIA 568A and 568B
Environmental Conditions
Operating Ambient Temp.: 0 to 40°C (32°to 104°F)
Storage Temp.: -20°to 70°C (-4°to 158°F)
Operating Humidity: 10 ...
Specifications: Height:
1.3U / 2U
2U with the supplied front plate
Dimensions (height x width x depth): 2.32" x 18.98" x 8.54"
Number of connections brought to the front: 10
Console port to the front: Yes
Cables: 10x 0.5m cables
Couplers:
9x RJ45 couplers
1x USB Couplers
Supported Models:
Sophos XGS 87
Sophos XGS 107
What's in the box?
- 1x SoRack + couplers
- 1x Rackmount.IT front plate
- Cables
- Assembly materials
- Installation guide
Specifications: Compatibility: Cisco FirePOWER Firewall, ASR9000 Router, ASR1000 Router, C9300 Switch, C3850 Switch
Cable Length: 32.81 ft
Data Transfer Rate: 10 Gbit/s
Features: Active, Hot-swappable
Cable Type: Twinaxial
Connector Type on First End: SFP+ Network - Male
Connector Type on Second End: SFP+ Network - Male
American Wire Gauge: 30 AWG
Connector on First End Details: 1 x SFP+ Network - Male
Connector on Second End Details1 x SFP+ Network – Male
Weight: 0.78lbs
Specifications: Industry Standards
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
2 - RJ-45 Female
1 - Terminal Block (6 Wire)
Max Distance: 100 m / 330 ft
Maximum Data Transfer Rate: 1Gbps
Power Output
Standard PoE+: 30 Watts max
Non-Standard PoE: 60 Watts max
Power Input Voltage: 20 ~ 57 DC
Steel
Dimension: 5.6" X 4.2" X 1.5" (L x W x H)
Specifications: Dimensions: 2.8 x 2.8 x 0.7 in. (71 x 71 x 16.6 mm)
Output Interface: 4 USB 3.0 Ports
Input Interface: USB 3.0 Type-A
Chipset: VIA VL812 Chipset with Latest Firmware
Supported Systems: Windows, Mac OS X and Linux systems
