Specifications: Dimensions: 7.73 x 3.68 x 1.28"
Weight: 0.63 lb.
Interface Connections:
1 x 1 Gbps SFP Port
1 x DC Terminal Block
1 x DC RJ45 Port DC Injection
1 x 1000 Mbps Ethernet PoE Port
Typical Power Consumption 1.5W
PoE Output: PoE RJ45 Port, 2-Pair (4, 5+; 7, 8-) (24V DC), or 4-Pair (24V DC or 50V DC) PoE
DC Output: Terminal Block, 2-Wire (24V DC or 50V DC)
Input DC Voltage: 16 to 57V
Specifications: Description: 8 Digital Inputs and 8 Digital Outputs
Digital Inputs: 8
Logic Level 0: -30.0V to +1.0V
Logic Level 1: +2.0V to +30V
Latched Inputs: Triggered by user programmable positive or negative edges, stays true until acknowledged
Counter Inputs: User progammable- counts positive or negative transitions up to 100Hz
Watchdog: Active high/low, Pulsed high/low
Digital Outputs: 8
Digital Output Type: Open drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min
Maximum Output Load Voltage: 30 VDC
Maximum Output Current Sink: 0.85A per channel
Serial Gateway: RS485 NuDam/ADAM compatible gateway
Number of Ports: 1
Network Port Type: RJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX)
Network Protocols: ICMP, IP, TCP, DHCP, HTTP
Protection: 1500V M...
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
Device Interface:
1 x Gigabit PoE/PoE+ in port
1 x Gigabit PoE/PoE+ out port
1 x Power port (optional power adapter is not included)
LED indicators
Installation mounting points
Data Transfer Rate:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Power:
Powered by PoE/PoE+ Device
Consumption: 2 Watts (max.)
Specifications: Power Method: 100-240V AC / 50-60 Hz, Universal Input
Power Supply:
54V, 150W AC/DC
Installed in PSU 1
Maximum Power Output:
150W (1 PSU module)
300W (2 PSU modules @ 150 W each)
LEDs:
Power: System on / off
Ethernet: Management port link
PSU: PSU1+PSU2, PSU1 / PSU2
Networking Interface: 1 x RJ-45 Fast Ethernet port
Rack Mount: Yes, 1U high
ESD/EMP Protection: Air +/- 24 kV; Contact +/- 24 kV
