Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both Mid-span and End-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DCStandards Compliance:
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Flush-frame acoustic ceiling bracket for ZoneFlex R710.
Flush-frame only - not applicable for standard (recessed-frame) acoustic ceiling.
Kit Content:
1 x Mounting bracket
2 x Mounting guide
Specifications: Networking Interface:
PoE In (802.3af): 1 x Gigabit RJ45 Port
PoE Out (24V Passive): 1 x Gigabit RJ45 Port
Operating Temperature: 0 to 70 degree C (32 to 158 degree F)
Power Input: 48V, 802.3af
Max. Power Output: 24V, 0.5A
Power Method:
24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Specifications: Video Channel: 1 channel bi-direction
Signal Mode: NTSC / PAL / SECAM
Video Connector: BNC
Video Bandwidth: 60MHz
Video Input / Output Voltage: 1.0 Vpp / typical peak-to-peak value
Video Input / Output Impedance: 75ohm / unbalanced interface
Supported Video Type:
1080p: AHD / TVI / CVI
480p: CVBS
Video Digital Bit Width: 8 / 10 bit
Differential Gain (DG): < 1.3% (typical value)
Differential Phase (DP): < 1.3 degree (typical value)
SNR Weighted: > 67 dB (typical value)
Data Channel: 1 channel
Physical Protocol: RS485
Operation Mode: Simplex
Data Connector: 3-pin terminal block with screw clamps
Data Rate: DC-115.2 Kbps
Bit Error Rate (BER): < 10ns
LED Indicators:
Power
Video
Link (fiber optic)
Power Requirement: 5V DC, 2A
Power Consumption: 4.8 watts (maximum)
Mechanical: Metal
Installation: Wall-mountable, DIN-rail (with ...
Specifications: Cable Type: Twinaxial
Cable Length: 4.92 ft
Connector On First End: 1 x SFP+ Network
Connector On Second End: 1 x SFP+ Network
Device Supported: Network Device
Data Transfer Rate: 1.25 GB/s
Specifications: Technical Information
Host Interface:
USB 3.0 Type A
Interfaces/Ports
Total Number of USB Ports:
3
Number of USB 3.0 Ports:
3
Number of Network (RJ-45) Ports:
1
Software
Operating System Supported:
Windows XP
Windows Vista
Windows 7
Windows 8
Windows 8.1
Windows 10
Windows 11
Windows Server 2003
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022
Mac OS X 10.6 Snow Leopard
Mac OS X 10.8 Mountain Lion
Mac OS X 10.10 Yosemite
Mac OS X 10.11 El Capitan
Mac OS X 10.12 Sierra
Mac OS X 10.13 High Sierra
Mac OS X 10.14 Mojave
Mac OS X 10.15 Catalina
Mac OS X 11.0 Big Sur
Mac OS X 12.0 Monterey
Mac OS X 13.0 Ventura
ChromeOS
Linux...
Specifications: xDirect232 Single Port RS232 10/100 Device Server
Serial Connectors: Single-port: DB9F RS232 (DCE Pinned)
Ethernet Interface: 10/100M RJ-45
Serial Interface Baud Rate: 300bps to 921.6 Kbps
LED Indicators: Power/Status, Link, Activity, Serial RX Activity & TX Activity
CPU: Based on DSTni-EX Enhanced 16-bit x86 Architecture
Memory: 256 KB SRAM, 1 MB Flash
100-240 VAC International Power Supply with Regional Adapters.
Specifications: Ethernet Interface:
Copper:
10/100BASE-TX RJ45
auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE-in-use
LNK / ACT
ESD Protection: 4KV DC
Enclosure: Metal case
Installation: Wall mount or DIN rail with optional kit
Power Requirements: BNC Power over Coaxial Input: 44~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet Plus(802.3at Type 2)
Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both mid-span and end-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Interfaces/Ports: 1 x RJ-45
Data Transfer Rate: 230 Kbps Serial
Management: SNMP
Protocols:
Telnet
Reverse Telnet
PPP
SSH v2
HTTP
DHCP
ARP
RARP
TCP
UDP
Status Indicators: Link / Power
Input Voltage:
100 V AC to 240 V AC
9 V DC to 30 V DC
Input Current:
400 mA 12 V DC
500 mA 9 V DC to30 V DC
