Specifications: 4 RJ-45 autosensing 10/100/1000 ports
2 RJ-45 dual-personality 10/100/1000 ports
1 RJ-45 serial console port
Power: 100-127 VAC / 200-240 VAC; 50 /60 Hz
Mounting:
MSM720 controller supports the mounting options of the 2520-8 port, including EIA-standard 19 in. Telco rack or equipment cabinet (rack-mounting kit included); horizontal surface or wall mounting.
Minimum dimensions (W x D x H): 15.95 x 25.4 x 4.45 cm
Weight: 1.64 kg
Form Factor:
Wall Mountable
Rack-mountable
Specifications: 32 x serial - RS-232 - RJ-45
1 x management - console - RJ-45
1 x network - Ethernet 10Base-T/100Base-TX - RJ-45
Total Expansion Slots: 1
Memory: 64MB SDRAM
Input Voltage: 110 - 220 V AC
Form Factor: Rack-mountable
Dimensions: 17.0" x 8.5" x 1.8"
Weight: 5.8 lbs.
Specifications: Description: IEEE 802.3af PoE compliant or 48 VDC input from included AC power supply
Voltage: 100-240 VAC
Current: 1.0 / 0.4 A
Frequency: 50 / 60 Hz
Specifications: Input Voltage Type: AC
Output Power: 150 W
Form Factor: Internal
Compatible with:
HP 4800-24G Switch
HP 4800-24G-PoE Switch
HP 4800-24G-SFP Switch
HP 4800-48G Switch
HP 4800-48G-PoE Switch
HP 5500-24G DC EI Switch
HP 5500-24G EI Switch
HP 5500-24G EI Switch Configured to Order
HP 5500-24G EI TAA-compliant Switch with 2 Interface Slots
HP 5500-24G EI TAA-compliant Switch with 2 Interface Slots Configured to Order
HP 5500-24G-PoE EI Switch
HP 5500-24G-PoE+ EI Switch with 2 Interface Slots
HP 5500-24G-PoE+ EI Switch with 2 Interface Slots Configured to Order
HP 5500-24G-PoE+ EI TAA-compliant Switch w/2 Interface Slots Configured to Order
HP 5500-24G-PoE+ EI TAA-compliant Switch with 2 Interface Slots
HP 5500-24G-SFP DC EI Switch
HP 5500-24G-SFP EI Switch
HP 5500-24G-SFP EI Switch Configured to Order
HP...
Specifications: Interface:
2 x 10/100/1000Mbps RJ45 Port, AUTO Negotiation/AUTO MDI/MDIX
1 x 48VDC POWER INPUT PORT
Network Media
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Basic Function:
Compatible With IEEE 802.3af Compliant PDs
Delivers Power Up To 100 Meters
Auto-Determine The Necessary Power Requirements
Dimensions: 3.2" x 2.1" x 0.9"
LED Indicator: PWR
Power Supply: 15.4W (Max. 48VDC)
Certification: FCC, CE, RoHS
System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
Environment
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -40°...
Specifications: Input Voltage Range:
AC 100 - 240 V
Frequency Required:
50/60 Hz
Interfaces:
1 x Gigabit LAN - RJ-45
Compliant Standards:
FCC Class B certified, EN 60950, EN55024, UL 60950, CISPR 22, EN55022 Class B, FCC Part 15
Compatibility:
HP M200 802.11n, MSM310, MSM310-R, MSM313, MSM320, MSM320-R, MSM325, MSM335, MSM710
Specifications: Device Supported: Power Supply
Application: X410 E-series 1U Universal 4-post Rack
Compatible with:
HP 1810-24G Switch
HP 1810-8G Switch
HP 2510-24 Switch
HP 2510-24G Switch
HP 2510-48 Switch
HP 2510-48G Switch
HP 2520-24G-PoE Switch
HP 2520-24-PoE Switch
HP 2520-8G-PoE Switch
HP 2520-8-PoE Switch
HP 2810-24G Switch
HP 2810-48G Switch
HP 2910-24G al Switch
HP 2910-24G-PoE+ al Switch
HP 2910-48G al Switch
HP 2910-48G-PoE+ al Switch
HP 3500-24 Switch
HP 3500-24G-PoE yl Switch
HP 3500-24G-PoE+ yl Switch
HP 3500-48 Switch
HP 3500-48G-PoE yl Switch
HP 3500-48G-PoE+ yl Switch
HP 3500-48-PoE Switch
HP 1810-48G Switch
HP 2620-24 Switch
HP 2620-24-PoE+ Switch
HP 2620-24-PPoE+ Switch
HP 2620-48 Switch
HP 2620-48-PoE+ Switch
HP 3800-24G-2SFP+ Switch
HP 3800-24G-2XG Switch
HP 3800-24G-PoE+-2SFP+ Switch
...
Specifications: Voltage: 200-240 VAC
Current: 10 A
Maximum power rating: 1800 W
Frequency: 50 / 60 Hz
Dimensions: 6.05" x 7.45" x 5.1"
Weight: 7.5 lbs.
Specifications: No. of Ports: 12
Pass Through Data Rates 10/100/1000 Mbps
PoE Output:
Pin Assignment and Polarity:
Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54-57V DC
User Port Power: 72W Typ.
Aggregate Power: 1000W
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
DC Input: 57V (RPS or another 9500G midspan)
AC Input Current: 450W Units: 5.5A @ 110V AC; 2.75A @ 220V AC
1000W Units: 12A @ 110V AC; 6A @ 220V AC
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators:
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green / Orange)
Connectors:
PoE ports and management port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
Specifications: Form Factor: Plug-in module
Ports: 10Gb Ethernet x 8
Connectivity Technology: Wired
Data Link Protocol: 10 GigE
Interfaces: 8 x 10GBase-T - RJ-45
