Specifications: Description: 8 Digital Inputs and 8 Digital Outputs
Digital Inputs: 8
Logic Level 0: -30.0V to +1.0V
Logic Level 1: +2.0V to +30V
Latched Inputs: Triggered by user programmable positive or negative edges, stays true until acknowledged
Counter Inputs: User progammable- counts positive or negative transitions up to 100Hz
Watchdog: Active high/low, Pulsed high/low
Digital Outputs: 8
Digital Output Type: Open drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min
Maximum Output Load Voltage: 30 VDC
Maximum Output Current Sink: 0.85A per channel
Serial Gateway: RS485 NuDam/ADAM compatible gateway
Number of Ports: 1
Network Port Type: RJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX)
Network Protocols: ICMP, IP, TCP, DHCP, HTTP
Protection: 1500V M...
Features: Device Protection
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.
Convenient Wall-Mounting
The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets.
Seamless airGateway Compatibility
The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway to bridge airMAX connections to Wi-Fi at customer locations.
Specifications: Ethernet Interface:
Copper:
10/100BASE-TX RJ45
auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE-in-use
LNK / ACT
ESD Protection: 4KV DC
Enclosure: Metal case
Installation: Wall mount or DIN rail with optional kit
Power Requirements: BNC Power over Coaxial Input: 44~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet Plus(802.3at Type 2)
Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both mid-span and end-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Cable Type: Twinaxial
Cable Length: 4.92 ft
Connector On First End: 1 x SFP+ Network
Connector On Second End: 1 x SFP+ Network
Device Supported: Network Device
Data Transfer Rate: 1.25 GB/s
Specifications: Hardware Version: 2
Interface:
"Data" Input Ports: 4 x RJ-45
"Data+Power" Output Ports: 4 x RJ-45
Data Rate: 10/100/1000 Mbps
LED:
System: Power x 1 (Green)
Per PoE Port: PoE ready / in-use x 4 (Green)
Network Cable:
10Base-T: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
100Base-TX: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
1000Base-T: 4-Pair UTP Cat. 5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m, 328 ft.)
Power Requirements: DC 52V~56V
PoE Power Supply Type: Mid-Span
PoE Power Output: Per Port DC 52V 30.8 watts / 15.4 watts
Power Pin Assignment: 4/5(+), 7/8(-)
PoE Power Budget: 120 watts
Number of 802.3af PD Class 0, 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 0, 4 can be powered: 4
Standards Compliance:
IEEE 802.3 10Bas...
Specifications: Technical Information
Protection Type:
ESD Protection
Power Description
Input Voltage:
120 V AC
230 V AC
Maximum Output Voltage:
54 V DC
Maximum Input Current:
2.50 A
Maximum Output Current:
3.30 A
Maximum Output Power:
160 W
Interfaces/Ports
Output Ports:
4 x Multi-Gigabit PoE++
Physical Characteristics
Product Color:
Black
Form Factor:
DIN Rail/Wall Mountable
Height:
1.5"
Width:
2.8"
Length:
3.7"
Weight (Approximate):
9.80 oz
Miscellaneous
Package Contents:
PoE++ Injector
1 x Universal Power Adapter
1 x DIN Rail Mounting Kit
1 x Quick-Start Guide
Compatibility:
IP cameras
access control devices
remote kiosks (POSs)
wireless access points
PoE lighting
digital signage.
Certifications & Standards:
IEEE 802.3af
IEEE...
Specifications: Multipurpose mounting bracket for indoor AP's supports mounting to hard wall, ceiling, pole or truss. Supports padlock security with ZoneFlex R710.
Kit Content:
1 x Sheet metal mounting bracket
2 x #6 wood screws & anchors
Specifications: PoE Standard: IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High Power over Ethernet)
PoE Power Supply Type: Mid-Span / Type B
PoE Power Output: 52V DC, 510 mA, Max. 26 watts
Power Pin Assignment: 4/5 (+), 7/8 (-)
Maximum Distance: 4 units, daisy-chain installation with 500m support
Data Rate: 10/100/1000 Mbps
Switch Architecture: Store-and-Forward
Maximum Frame Size: 1552 Bytes
Flow Control:
Back pressure for half-duplex
IEEE 802.3x pause frame for full-duplex
LED Indicators:
1 x PoE IN (Green)
1 x LAN Data (Green)
1 x PoE OUT (Green)
Power Requirements: IEEE 802.3at compliant with voltage within 52V-56V DC
Power Consumption: 3.2 watts (system maximum)
