Specifications: Technical Information
Host Interface:
USB 3.0 Type A
Interfaces/Ports
Total Number of USB Ports:
3
Number of USB 3.0 Ports:
3
Number of Network (RJ-45) Ports:
1
Software
Operating System Supported:
Windows XP
Windows Vista
Windows 7
Windows 8
Windows 8.1
Windows 10
Windows 11
Windows Server 2003
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022
Mac OS X 10.6 Snow Leopard
Mac OS X 10.8 Mountain Lion
Mac OS X 10.10 Yosemite
Mac OS X 10.11 El Capitan
Mac OS X 10.12 Sierra
Mac OS X 10.13 High Sierra
Mac OS X 10.14 Mojave
Mac OS X 10.15 Catalina
Mac OS X 11.0 Big Sur
Mac OS X 12.0 Monterey
Mac OS X 13.0 Ventura
ChromeOS
Linux...
Specifications: Interface:
"Data" Input Port: 1 x RJ-45 STP
"PoE (Data+Power)" Output Port: 1 x RJ-45 STP
Input power terminal block: 1
LED Indicator:
System: Power 1, Power 2, Fault (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
10Base-T: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000Mbps
Dimension: 1.26" x 5.31" x 3.46"
Weight: 1.05 lbs.
Unit Input Voltage: 24 - 48V DC; 24V AC
Power Consumption: 30 watts max.
Number of device can be powered: 1
Installation: DIN rail kit and wall mount ear
Alarm:
Provides one relay output for power failure,
Alarm relay current carry ability: 3A at DC 30V
Enclosure: IP30 slim type metal case
Power over Ethernet
PoE Standard: IEEE 802.3at High ...
Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.]
Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.]
Standards: IEEE 802.3
Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes
Status LEDs:
PWR (Power): (below RJ-45)
ON = Lit for normal operation
FX-Link/Act (Fiber Link/Activity):
(Upper Left on RJ-45)
ON = Link; Flashing = Activity
TX-Link/Act (Copper Link/Activity):
(Upper Right on RJ-45)
ON = Link; Flashing = Activity
Power
Consumption: 3.15 Watts
Sources: Unit accepts 5 VDC to 28 VDC
Wall Mount AC adapter: 12 VDC 400mA
Environment
Storage: -15 to +65 °C
Operating: 0°C to 50°C
Altitude: 0 – 10,000 feet
Humidity: 5% to 95% (non-condensing)
Compliance
Safety: Wall Mount Power Supply, UL Listed,
C-UL Listed ...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Multi-mode
Fiber Optic Cable Wavelength:
0 mil
Maximum Distance Supported:
0.55 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
Co...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Single-mode
Fiber Optic Cable Wavelength:
0.1 mil
Maximum Distance Supported:
40 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of LC Ports:
1
LC Port Type:
Duplex
Number of Network (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Fiber Optic Cable Wavelength:
0 mil
Maximum Distance Supported:
0.55 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
Color ...
Specifications: What's in the box:
Digi Connect EZ Mini - serial server, 1-port, with accessories
Power supply - 12 V, 2.5 A (76000823)
DIN rail clip (76002095)
Specifications: PoE Standard: IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High Power over Ethernet)
PoE Power Supply Type: Mid-Span / Type B
PoE Power Output: 52V DC, 510 mA, Max. 26 watts
Power Pin Assignment: 4/5 (+), 7/8 (-)
Maximum Distance: 4 units, daisy-chain installation with 500m support
Data Rate: 10/100/1000 Mbps
Switch Architecture: Store-and-Forward
Maximum Frame Size: 1552 Bytes
Flow Control:
Back pressure for half-duplex
IEEE 802.3x pause frame for full-duplex
LED Indicators:
1 x PoE IN (Green)
1 x LAN Data (Green)
1 x PoE OUT (Green)
Power Requirements: IEEE 802.3at compliant with voltage within 52V-56V DC
Power Consumption: 3.2 watts (system maximum)
Specifications: Hardware Version: 4
Interface:
Data Input Ports: 24 x RJ45
Data + Power Output Ports: 24 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000 Mbps
LED:
System:
1 x SYS PWR (Green)
1 x PoE1 Fail (Red)
1 x PoE2 Fail (Red)
1 x Fan1 Fail (Red)
1 x Fan2 Fail (Red)
Per PoE Port: 1 x PoE-in-Use (Green)
2 x Management port: 1000 (Green), 10/100 (Orange)
Network Cable:
10BASE-T: 4-pair UTP Cat5 up to 100m (328 ft.)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328 ft.)
1000BASE-T: 4-pair UTP Cat5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Power Requirements: 100-240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts max.
Cooling: 3 x Fan
PoE Power Supply Type: Mid-span
PoE Power Output: Per port DC 50-57V 30.8 / 15.4 watts
Power Pin Assignment...
Specifications: Dimensions: 3.80" x 1.20" x 0.90"
Output Interface:
3 x USB-A 3.0 Ports
1 x Gigabit Ethernet Port
Input Interface: 1 x USB-A 3.0 Connector
Chipset: RTL8153
Supported Systems: Windows (XP / Vista / 7 / 8 / 8.1 / 10), Mac OS X (10.5-10.11), Linux OS and Chrome OS
Package Contents:
USB 3.0 3-Port Hub & Gigabit Ethernet Adapter UE330
User Guide
Features: High Speed
USB 3.0 & Gigabit - Equipped with USB 3.0 ports and Gigabit Ethernet port, UE306 provides a high speed data transfer rate
Portable Devices
Compact Design - Compact design with a retractable cable makes it an ideal on the go
Plug and Play
User Friendly - For Windows10, Nintendo Switch, Linux(Ubuntu), the adapter is plug and play, and enjoy the most stable and rapid Internet
