Specifications: Interface:
"Data" Input Ports: 16 x RJ45
"Data + Power" Output Ports: 16 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000Mbps
LED
System: SYS PWR x 1 (Green), PoE Failure x 1 (Red), Fan Failure x 2 (Red)
Management port x 2: 1000 (Green), 10/100(Orange)
Per PoE Port: Ultra 60W PoE-in-use x 1 (Green), 802.3at/af PoE-in-use x1 (Orange), PoE Power Usage LED x4 (Green)
Power Requirements: 100 - 240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts (max.) / 2729BTU
Ventilation: Fan x 3
Enclosure: Metal
PoE Standard:
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE
PoE Power Supply Type: End-span / Mid-span / UPoE (Ultra PoE)
Power Pin Assignment:
Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),...
Specifications: Safety
IEC 60950-1, EN 60950-1, CB Certificate/Report, UL/CSA 60950-1
EMC
CC / ICES-003 Emission (USA/Canada)
CRISP 22 Emission (International)
EN61000-4-2 Electrostatic Discharge
EN61000-4-3 Radiated RFI Immunity
EN61000-4-4 Electrical Fast Transients level 4
EN61000-4-5 Electrical Surge Level
EN61000-4-6 RF Conducted
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
Specifications: Standards
802.3 10BaseT
802.3u 100BaseT
802.3ab Gigabit Ethernet
Proprietary PoE
Physical Interface
1) Gigabit Data Port
(1) Gigabit Data & Power Output Port
(1) IEC-320 C6 AC Connector
Power
Input voltage : 100 to 240 VAC
Input current: 0.8A maximum for 100 VAC
AC input Frequency: 47-63Hz
Maximum output power: 32.8W
Pin4, 5:54V; Pin7, 8: Return
Temperature Range
Operating: 32 degree F to 104 degree F (0 degree C to 40 degree C)
Storage: -22 degree F to 176 degree F (-30 degree C to 80 degree C)
Humidity (non-condensing)
Operating: 5 to 90% or less
Storage: 5 to 90% or less
LED Indicator: 1 x Power on Green
Mounting: Wall (anchors & screws included)
Dimensions: 1.30" x 3.90" x 2.27"
Parts: Manufacturers Limited Warranty: 1 Year / Parts Only
Specifications: Interfaces:
PoE IN:1 x 10/100/1000BASE-T Ethernet with IEEE 802.3at PoE "Data + DC power" in auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE OUT: 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/802.3af PoE "Data + DC power" out auto MDI/MDI-X, auto-negotiation RJ45 connector
Power over Ethernet
PoE Standard:
"PoE In" Port: IEEE 802.3at Power over Ethernet Plus end-span/mid-span PD class 4 PD
Per "PoE Out" Port:
IEEE 802.3at Power over Ethernet Plus end-span PSE
IEEE 802.3af Power over Ethernet end-span PSE
PoE Power Supply Type: End-span (Type A)
PoE Power:
"PoE In" Port: 52 - 56V DC, max. 30.8 watts
Per "PoE Out" Port: 44 - 55V DC, max. 25 watts
Power Pin Assignment:
"PoE In" Port: 1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)
Per "PoE Out" Port: 1/2 (+), 3/6 (-)
Data Rate: 10/100/1000Mbps
MAC Address Table: 2K
Data Bu...
Specifications: Kit Content:
1 x Country-specific power cord, IEC, 6 ft.
1 x Power adapter
Input: 100 - 240V AC, 50/60Hz 0.6A
Output: 12V DC 2.0A
AC plug: country-specific
DC plug: Right-angle, 2.5 x 5.5 x 10 mm (ID x OD x L) female, positive center
DC cable length 1.5m
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate...
Specifications: Network Technology: 1000Base-TX, 1000Base-T
Power Description Plug/Connector Type: Terminal Block (3 Wire), Type N
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Total Number of Expansion Slots: 1.0
Network (RJ-45): Yes
Number of PoE (RJ-45) Ports: 1
Total Number of Ports: 1
Media Type Supported: Twisted Pair
Fiber Mode Supported: Optical Fiber, Single-mode, Multi-mode
Weight (Approximate) 2.80 oz
Height 1.9", Width 1.4", Depth 2.3"
Environmental Compliance: Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
...
Specifications: Hardware Version: 4
Interface:
Data Input Ports: 24 x RJ45
Data + Power Output Ports: 24 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000 Mbps
LED:
System:
1 x SYS PWR (Green)
1 x PoE1 Fail (Red)
1 x PoE2 Fail (Red)
1 x Fan1 Fail (Red)
1 x Fan2 Fail (Red)
Per PoE Port: 1 x PoE-in-Use (Green)
2 x Management port: 1000 (Green), 10/100 (Orange)
Network Cable:
10BASE-T: 4-pair UTP Cat5 up to 100m (328 ft.)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328 ft.)
1000BASE-T: 4-pair UTP Cat5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Power Requirements: 100-240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts max.
Cooling: 3 x Fan
PoE Power Supply Type: Mid-span
PoE Power Output: Per port DC 50-57V 30.8 / 15.4 watts
Power Pin Assignment...
Features: HIGH POWER GIGABIT PoE SPLITTER: Power non-PoE devices using network infrastructure where power isn't available / Splits PoE connection (max 90W) into RJ45 data & DC power (terminal block)
90W POE IEEE802.3bt: Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), IEEE 802.3bt (PoE++ / Type 3); power out configured w/ DIP switch for 12/16/24/48V DC (1.5A) via terminal block
TECH SPECS: High Speed 1 Gbps / 1 x RJ45 PoE In / 1 x RJ45 Dat...
