Learn more about the TRENDnet TI-EU120
Model| Brand | TRENDnet |
|---|
| Model | TI-EU120 |
|---|
Details| Type | UPoE Extender |
|---|
| Specifications | Standards: IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3bt draft
Device Interface: 1 x IP67 weather rated gigabit UPoE input port 2 x IP67 weather rated gigabit UPoE output ports LED indicators
Data Transfer Rate: Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex) Gigabit: 2000 Mbps (full duplex)
Performance: RAM Buffer: 1MB MAC Address Table: 8K Jumbo Frame: 10KB
Power: PD power input: 30W/60W/95W PoE 15W/30W/60W per PSE PoE Budget: 64W Max. Consumption: 3W Max. (without PoE) |
|---|
Features| Features | Easy installation
Extends 100m for a total distance of up to 200m (656 ft.)
Daisy chain up to 4 units for a total PoE network extension of up to 500m (1640 ft.)
Use a single UPoE connection to extend PoE for up to two devices
Supports PoE (15.4W), PoE+ (30W), UPoE (60W) devices
Wide operating temperature range of -40 degree - 75 degree C (-40 degree - 167 degree F)
IP67 outdoor weather rated housing
No external power adapter required
Built-in True Surge 6kV Protection |
|---|
Additional Information| First Listed on Newegg | February 24, 2023 |
|---|
