Quick View
Intel HNS2600TP Compute Module- Type: Compute Module
- Specifications: Compatible Product Series: Intel Xeon processor E5-2600 v3 product family
Board Form Factor: Custom 6.8" x 18.9"
Chassis Form Factor: Rack
Socket: Socket R3
TDP: 145 W
Max Memory Size (dependent on memory type): 1024 GB
Memory Types DDR4 ECC RDIMM 1600, 1866, 2133/ LRDIMM 1600, 1866, 2133
Max # of Memory Channels: 8
Max Memory Bandwidth: 115 GB/s
Physical Address Extensions: 46-bit
Max # of DIMMs: 16
- Model #: HNS2600TP

Quick View
Intel RES2CV240 RAID Expander Card- Type: RAID Expander Card
- Specifications: IO Processor Model: LSI 6Gb SAS2x24 expander
Data Transfer Rate: 6 Gb/s
Supported Devices: SAS/SATA
RAID Level Supported: Dependent on paired RAID card
- Model #: RES2CV240

Quick View
Intel AXXRSBBU6 Raid Smart Battery- Type: RAID Battery
- Specifications: General
Device Type: Memory backup battery
Battery Enclosure Type: Internal
Width: 2.6 in
Depth: 2.1 in
Weight: 1.4 oz
Battery
Quantity: 1
Technology: Lithium ion
Voltage Provided: 3.7 V
Capacity: 700 mAh
Run Time (Up To): 72 hrs
Recharge Time: 8 hour(s)
Max Recharge Cycles: 500
Miscellaneous
MTBF: 2,490,772 hour(s)
- Parts: 30 DAYS WARRANTY
- Labor: 30 DAYS WARRANTY
- Model #: AXXRSBBU6
