At803 Omnidirectional Condenser Lavalier Microphone- Type: Pro Audio - Microphones
- Connectors: Output Connector (Power Module): Integral 3-pin XLRM-type
- Audio: Element: Fixed-charge back plate, permanently polarized condenser
Polar Pattern: Omnidirectional
Frequency Response: 30-20,000 Hz
Low Frequency Roll-Off: 80 Hz, 18 dB/octave
Open Circuit Sensitivity Phantom: -44 dB (5.6 mV) re 1V at 1 Pa
Open Circuit Sensitivity Battery: -46 dB (5.6 mV) re 1V at 1 Pa
Phantom Impedance: 200 ohms
Battery Impedance: 270 ohms
Phantom Maximum Input Sound Level: 135 dB SPL, 1 kHz at 1% T.H.D.
Battery Maximum Input Sound Level: 121 dB SPL, 1 kHz at 1% T.H.D.
Phantom Dynamic Range (Typical): 107 dB, 1 kHz at Max SPL
Battery Dynamic Range (Typical): 93 dB, 1 kHz at Max SPL
SNR: 66 dB, 1 kHz at 1 Pa
Phantom Power Requirements: 11-52V DC, 2 mA typical
Switch: Off, on-flat, on-roll-off
- Power Requirem...
- Model #: AT803
