Specifications: Interface:
Input Port
1 x RJ-45 STP
Data In
Output Port
1 x RJ-45 STP
PoE (Data + Power) Out
DC socket
56V DC Input
LED Indicator:
System: Power x 1 (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
Ultra PoE (60W): 10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328 ft.)
802.3af/at PoE(15W / 30W): 10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328 ft.)
Data Rate: 10/100/1000 Mbps
Unit Input Voltage: DC 56V
Power Requirements:
External AC-to-DC adapter
100-240V AC, 50/60 Hz, 1.5A
Power Consumption: 65 watts max.
PoE Standard: IEEE 802.3at High Power over Ethernet End-span / Mid-span PSE
Power Output:
DC 56V / 60-watt PoE via 4-pairs
DC 56V / 30-watt PoE via 2-pairs
PoE Power Supply Type: End-Span + Mid-Span
Power Pin Assignment:
Pair 1: 1/2 (-), 3/6 (+)
Pair 2: 4/5 (+), ...
Specifications: Type: Power Supply - Hot-plug / Redundant
Input Voltage: AC 100-240 V
Frequency Required: 50/60 Hz
Input Connector(s): Power IEC 320 EN 60320 C13
Power Capacity: 1000 Watt
Specifications: Number of Ports: 2 (1 for data in, 1 for data and power out)
Pass-through Data Rates: 10/100/1000 Mbps
Maximum Cable Run: 100 meters or 330 feet which corresponds to Ethernet limits
LED Indicator: Power On/Off and overload conditions
Connectors: Shielded RJ-45, EIA 568A and 568B
MTBF: 100,000 hrs. at 25 ºC
Power over Ethernet Output:
Pin Assignment and Polarity: 4/5 (+), 7/8 (–)
Output Power Voltage: 50V DC
Output Power: 15.4 Watts
Input Power Requirements
AC Input Voltage: 90 to 264V AC
AC Input Current: 0.5A at 100 - 240V AC
AC Frequency: 47 - 63 Hz
Operating Ambient Temperature: 32 - 104ºF (0 - 40ºC)
Storage Temperature: -4 - 158ºF (-20 - 70ºC)
Operating Humidity: Maximum 90%, non-condensing
Storage Humidity: Maximum 95%, non-condensing
Operating Altitude: -1000 - 10,000 ft. (-304.8 - 3048 m)
Heat Dissipation: ...
