Xeon E-2200/E-2100 family 9th / 8th Gen Intel Core, Pentium Gold and Celeron® Processors
DDR4 2666
+
+
Overview
Specs
Reviews
Learn more about the ASUS PRO WS C246-ACE
Model
Brand
ASUS
Model
PRO WS C246-ACE
Supported CPU
CPU Socket Type
LGA 1151
CPU Type
Xeon E-2200/E-2100 family 9th / 8th Gen Intel Core, Pentium Gold and Celeron® Processors
Chipsets
Chipset
Intel C246
Memory
Number of Memory Slots
4x288pin (DDR4)
Memory Standard
DDR4 2666
Maximum Memory Supported
128GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 3.0 x16
2 x PCIe 3.0/2.0 x16 (x16 or dual x8) 1 x PCIe 3.0/2.0 x16 (max at x2 mode)
PCI Express x1
2 x PCIe 3.0/2.0 x1
Storage Devices
M.2
1 x M.2_1 socket 3, , with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 2 mode) 1 x U.2 connector
SATA RAID
0/1/5/10
Onboard Audio
Audio Chipset
Realtek ALC S1220A
Audio Channels
8-Channel High Definition Audio CODEC featuring Crystal Sound 3
Onboard LAN
Max LAN Speed
1Gbps
Rear Panel Ports
Back I/O Ports
1 x DisplayPort / 1 x HDMI / 1 x Optical S/PDIF Out / 1 x USB 3.2 Gen 2 Type-C / 2 x LAN (RJ45) / 3 x USB 3.2 Gen 2 Type-A / 4 x USB 3.1 Gen 1 / 5 x Audio Jacks
Internal I/O Connectors
Other Connectors
1 x AAFP connector 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & x2 PCIE mode) 4 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) () 1 x 24-pin EATX Power connector(s) 2 x 8-pin ATX 12V Power connector(s) 1 x Thermal sensor connector(s) 1 x Clear CMOS jumper(s) 1 x Node Connector(s) 1 x U.2 connector 1 x System panel connector 1 x COM port header 1 x AIO PUMP Header
Physical Spec
Form Factor
ATX
Dimensions (W x L)
12.0" x 9.6"
Packaging
Package Contents
User's manual I/O Shield 1 x M.2 Screw Package 1 x Supporting DVD
Additional Information
First Listed on Newegg
May 15, 2026
