Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors
DDR4 2666/2400/2133 MHz
+
+
Overview
Specs
Reviews
Intel B365 Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors DDR4 2666/2400/2133 MHz
Learn more about the ASUS B365M-Plus Gaming
Model
Brand
ASUS
Series
TUF
Model
B365M-Plus Gaming
Supported CPU
CPU Socket Type
LGA 1151 (300 Series)
CPU Type
Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors
Chipsets
Chipset
Intel B365
Onboard Video
Onboard Video Chipset
Intel HD Graphics
Memory
Number of Memory Slots
4x288pin (DDR4)
Memory Standard
DDR4 2666/2400/2133 MHz
Maximum Memory Supported
64GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 3.0 x16
1 x PCIe 3.0 x16 (x16 mode) 1 x PCIe 3.0 x16 (max at x4 mode)
PCI Express x1
1 x PCIe 3.0/2.0 x1
Storage Devices
Serial ATA (SATA)
6 x SATA 6Gb/s
M.2
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
Intel Optane Ready
Yes
SATA RAID
0/1/5/10
Onboard Audio
Audio Channels
8 Channels
Onboard LAN
LAN Chipset
Intel I219-V
Max LAN Speed
1Gbps
Rear Panel Ports
Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)1 x DVI-D1 x DisplayPort1 x HDMI1 x LAN (RJ45) port(s)4 x USB 3.1 Gen 1 Type-A up to 5Gbps2 x USB 2.0 8-channel Audio I/O
Internal I/O Connectors
Onboard USB
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin, moss green)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors
1 x Addressable RGB header1 x Aura RGB Strip Header2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices1 x COM port(s) connector(s)6 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s)2 x Chassis Fan connector(s)1 x S/PDIF out header(s)1 x Front panel audio connector(s) (AAFP)1 x Clear CMOS jumper(s)1 x System panel connector
Physical Spec
Form Factor
Micro ATX
Dimensions (W x L)
9.6" x 9.5"
Power Pin
1 x 24-pin EATX Power connector(s)1 x 8-pin EATX 12V Power connectors
Packaging
Package Contents
Accessories:User's manualI/O Shield2 x SATA 6Gb/s cable(s)2 x M.2 screws1 x Supporting DVD1 x TUF GAMING Sticker1 x TUF Certification card(s)
Additional Information
First Listed on Newegg
May 15, 2026
Customer Reviews of the ASUS B365M-Plus Gaming
There are no reviews yet.
Do you own this product?
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
Please contact the Seller directly for warranty information. Warranty information may also be found on the Manufacturer's website.
