HPE Aruba R8n85A 6000 48G Class4 PoE 4SFP 370W Switch - switch - 48 ports - managed - rack-mountable

Product

Specifications

General Device Type Switch - 48 ports - managed - stackable Enclosure Type Side to side airflow rack-mountable 1U Subtype Gigabit Ethernet Ports 48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP Power Over Ethernet (PoE) PoE PoE Budget 370
W Performance Packet buffer size: 12.38 MB |
Throughput: 77.3 Mpps |
Switching capacity: 104 Gbps |
Latency (1 Gbps): 1.9 µs
Capacity Switched virtual interfaces (SVIs): 16 |
ARP entries: 1024 |
IPv4 routes (Unicast): 512 |
IPv6 routes (Unicast): 512 |
IGMP groups: 512 |
MLD groups: 512 |
IPv4 ACL entries (ingress): 256 |
IPv6 ACL entries (ingress): 128 |
MAC ACL entries (ingress): 256 MAC Address Table Size 8192 entries Jumbo Frame Support 9198 bytes Routing Protocol IGM
Pv2, IGM
Pv3 Remote Management Protocol SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUS Encryption Algorithm SSL Authentication Method Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v. 2 (SSH2) Features Flow control, BOOTP support, ARP support, VLAN support, DiffServ support, IPv6 support, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, MLD snooping, Trusted Platform Module (TPM), fanless, LACP support, LLDP support, DHCP client, Management Information Base (MIB), Neighbor Discovery Protocol (NDP), SNMP support, Internet Control Message Protocol (ICMP), DNS client, LLDP-MED, User Datagram Protocol (UDP), Rapid Reconfiguration of Spanning Tree (RSTP), IPv6 addressing Compliant Standards IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3 ab, IEEE 802.1 p, IEEE 802.3 af, IEEE 802.3 x, IEEE 802.3 ad (LACP), IEEE 802.1 w, IEEE 802.1 s, IEEE 802.3 at, IEEE 802.3 az Processor 1 x ARM A 9: 1. 016 GHz RAM 4 GB DDR3 SDRAM Flash Memory 16 GB Expansion / Connectivity Interfaces 48 x 10/100/1000 Base-T RJ-45 PoE Class 4 - 370 W | 4 x Gigabit LAN SFP | 1 x USB Type A | 1 x USB-C console Power Power Device Internal power supply Voltage Required AC 100-240 V (50/60 Hz) Power Consumption Operational 45 Watt Miscellaneous Compliant Standards CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C 22.2 No.

60950, CNS 13438, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368- 1:2014, VCCI-CISPR 32:2016 Class A, CISPR 35, EN 55035:2017, EN
55032:2015 /AC: 2016-07 Class A, EN
55024:2010: A1, IEC 62368-1 Second Edition Dimensions & Weight Width 17.4 in Depth 12 in Height 1.7 in Weight 11.07 lbs Environmental Parameters Min Operating Temperature 32 °F Max Operating Temperature 113 °F Humidity Range Operating 15 - 95% (non-condensing) Humidity Range Storage 15 - 90% (non-condensing)
