MEAN WELL RSD-30G-24 24V 1.25A 30W Reliable Railway Enclosed DC-DC Converter 9-36 Vin

24V 1.25A 30W Reliable Railway Enclosed DC-DC Converter 9-36 Vin24 Volts DC @ 1.25 AmpsFeatures --Compliance to EN50155 and EN45545-2 railway standard--Ultra compact and 1U low profile (25mm) -- 4:1 wide input range--No minimum load required--Protections: Short circuit, overload, over voltage, input reverse polarity--4000 VDC I/O isolation--Half encapsulated, cooling by free air convection---40 to +70C wide working temperature--Built-in constant current limiting circuit--LED indicator for power on--Screw terminals--3 year warranty

Specifications

--Output voltage: 24
VDC--Output current: 1.25
Amps--Rated power: 30
Watts--Input voltage range: 9 to 36
VDC--Efficiency: 89%--Line
regulation: 0.2
%--Load regulation: 0.2 %--Ripple
& noise: 50
mVp-p--Size: 4.45"L x 2.36"W x 0.98"H --Agency approvals: CE Applications --Bus, tram, metro or railway systems--Highly vibrating, highly dusty, extremely low or high temperature harsh environment--Wireless network--Telecom or Datacom system--Industry control system
