Specifications: 1 x 8 Pin Terminal Block - 4 pins for 2 speakers, 2 pins for power input, 2 pins for power output
1 pair RCA (left/right) - Red for right and White for left - White also accepts Mono input
1 x 3.5mm Stereo Port - Stereo input
Class - Class D
Total Output Power - 40W
Output Power (THD 1%) - 13W per channel
THD+N (at 10W power output) - 0.3% per channel
Efficiency - >90%
Frequency Response - 150Hz to 20KHz
Signal to Noise Ratio - >85dB
Input Impedance (unbalanced) - ~10 Kohms
Auto Shutdown - Shuts down 5 minutes after no input signal detected
Max Operating Current - ~2000 mA
Current Draw In Shutdown Mode - 30 mA
Power Supply - 24V DC, 2.0A
Volume Controls - Independent controls to Input Channels
LED Indicators - Input Power (Red LED) Output Power (Green LED)
Dimensions: 1.34" x 4.65" x 5.00"...
Specifications: Mount Specifications
Material: Carbon Fiber
Weight: 2.00 lbs.
Length: 6" arm x 1
Total Span: 11.875" - 13.625"
Joints: 0.79" spherical joint at base x 1, 0.79" spherical joint at tablet connection x 1
Connection: MagConnect
Base Specifications: Adjusts to any flat surface maximum 1.67" and any round surface maximum 1.67" and minimum 0.38"
Module Specifications
Material: Plastic and VHB
Weight: 3 oz.
Width: 3.875"
Length: 6.625"
Depth: 0.16"
