Effortless PoE Network Growth — 8-Port Gigabit PoE+ Passthrough Switch
The Intellinet 8-Port Gigabit PoE+ Passthrough Switch gives you a powerful, plug-and-play way to expand your PoE network—no power adapter required. Its dedicated PD port accepts up to 90 W from modern Ultra PoE++ (4PPoE) sources, allowing you to pass both power and data through existing Ethernet runs with zero hassle. With eight Gigabit ports, you can connect and power up to seven PoE devices—including access points, IP cameras, and VoIP phones—while maintaining fast, reliable 1,000 Mbps network speeds. It’s the simplest and most efficient way to add more devices and extend your network exactly where you need it.
Extend your PoE reach with built-in passthrough
With advanced PoE passthrough technology, this unit extends your PoE connection from 100 m to 200 m (656 ft.), giving you twice the reach without adding complex wiring. Using it as a PoE Passthrough Switch eliminates the cost and hassle of installing new electrical lines, reducing clutter from power cables in ceilings and walls. It delivers up to 85 W to compatible devices, making long-distance deployments simpler, cleaner, and far more efficient.
Technical Specifications
 Intellinet PoE-Powered 8 Port Gigabit Switch with PoE Passthrough – One IEEE 802 |  Intellinet PoE Powered 6 Port Managed Gigabit Ethernet Switch with PoE |  Intellinet PoE-Powered 5 Port Gigabit Switch with PoE Passthrough |  Intellinet Outdoor Weatherproof 5 Port Gigabit Switch with Poe Passthrough | |
|---|---|---|---|---|
| Customer Reviews | — | — | — | — |
| Price | — no data | — no data | — no data | — no data |
| Intellinet Model Number | 561679 | 562034 | 561808 | 509220 |
| PoE Passthrough | ? | ? | ? | ? |
| Usable as a PoE Extneder | ? | ? | ? | ? |
| Indoor vs Outdoor Use | Indoor | Indoor | Indoor | Outdoor |
| Ports | 7 PoE Ports, 1 PoE Pd Port (with 90W Power Input), | 4 PoE Ports, 1 PoE Pd Port (with 95W Power Input), 2 RJ45 Gigabit Uplink Ports | 4 PoE Ports, 1 PoE Pd Port (with 95W Power Input) | 4 PoE Ports, 1 PoE Pd Port (with 90W Power Input) |
| PoE Power Budget | 85W | 60W | 65W | 85W |
| Max Power Output per Port | up to 30W per Port | up to 30W per Port | up to 30W per Port | up to 30W per Port |
| PoE Compatibility | IEEE 802.3 i/u/ab/af/at/bt/az/x | IEEE 802.1 p/q, IEEE 802.3z, IEEE 802.3 ab/af/at/u/x | IEEE 802.3 ab/af/at/bt/u/x | IEEE 802.3 ab/af/bt/u/x |
| Extender Distance | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device |
Effortless PoE Network Growth — 8-Port Gigabit PoE+ Passthrough Switch
The Intellinet 8-Port Gigabit PoE+ Passthrough Switch gives you a powerful, plug-and-play way to expand your PoE network—no power adapter required. Its dedicated PD port accepts up to 90 W from modern Ultra PoE++ (4PPoE) sources, allowing you to pass both power and data through existing Ethernet runs with zero hassle. With eight Gigabit ports, you can connect and power up to seven PoE devices—including access points, IP cameras, and VoIP phones—while maintaining fast, reliable 1,000 Mbps network speeds. It’s the simplest and most efficient way to add more devices and extend your network exactly where you need it.
Extend your PoE reach with built-in passthrough
With advanced PoE passthrough technology, this unit extends your PoE connection from 100 m to 200 m (656 ft.), giving you twice the reach without adding complex wiring. Using it as a PoE Passthrough Switch eliminates the cost and hassle of installing new electrical lines, reducing clutter from power cables in ceilings and walls. It delivers up to 85 W to compatible devices, making long-distance deployments simpler, cleaner, and far more efficient.
Technical Specifications
| Intellinet Model Number | 561679 |
| PoE++ Input Support | Accepts up to 90 W power input via IEEE 802.3bt (4PPoE) PD port. |
| PoE Passthrough Budget | Provides up to 85 W total PoE output power when powered via 802.3bt. |
| Seven PSE Ports | Powers up to seven PoE/PoE+ devices simultaneously. |
| Extended PoE Range | Doubles PoE transmission distance from 100 m to 200 m. |
| Gigabit Auto-Sensing | All eight ports support 10/100/1000 Mbps auto-negotiation. |
| Per-Port Power Output | Delivers up to 30 W PoE power per port. |
| Switch Fabric Capacity | 16 Gbps switching capacity/backplane bandwidth. |
| MAC Address Table | Supports 2,000 MAC entries with auto-learning/aging. |
| Energy-Saving Mode | Green Ethernet adjusts power based on cable length and disables idle ports. |
| PoE Protection Suite | Built-in short circuit, overload, and high-voltage protection. |
| Flow Control Support | IEEE 802.3x full-duplex flow control and half-duplex backpressure. |
| Fanless Cooling | Fanless metal housing for silent thermal operation. |
| Compact Metal Enclosure | 104 × 240 × 29 mm metal chassis; 660 g weight. |
| Operating Environment | Operates from 0–40°C and 10–90% non-condensing humidity. |
| Standards Compliance | Meets IEEE 802.3i/u/ab/af/at/bt/az/3x; FCC, CE, RoHS, UKCA, NDAA. |
Intellinet PoE-Powered 8 Port Gigabit Switch with PoE Passthrough – One IEEE 802 | Intellinet PoE Powered 6 Port Managed Gigabit Ethernet Switch with PoE | Intellinet PoE-Powered 5 Port Gigabit Switch with PoE Passthrough | Intellinet Outdoor Weatherproof 5 Port Gigabit Switch with Poe Passthrough | |
|---|---|---|---|---|
| Customer Reviews | — | — | — | — |
| Price | — no data | — no data | — no data | — no data |
| Intellinet Model Number | 561679 | 562034 | 561808 | 509220 |
| PoE Passthrough | ? | ? | ? | ? |
| Usable as a PoE Extneder | ? | ? | ? | ? |
| Indoor vs Outdoor Use | Indoor | Indoor | Indoor | Outdoor |
| Ports | 7 PoE Ports, 1 PoE Pd Port (with 90W Power Input), | 4 PoE Ports, 1 PoE Pd Port (with 95W Power Input), 2 RJ45 Gigabit Uplink Ports | 4 PoE Ports, 1 PoE Pd Port (with 95W Power Input) | 4 PoE Ports, 1 PoE Pd Port (with 90W Power Input) |
| PoE Power Budget | 85W | 60W | 65W | 85W |
| Max Power Output per Port | up to 30W per Port | up to 30W per Port | up to 30W per Port | up to 30W per Port |
| PoE Compatibility | IEEE 802.3 i/u/ab/af/at/bt/az/x | IEEE 802.1 p/q, IEEE 802.3z, IEEE 802.3 ab/af/at/u/x | IEEE 802.3 ab/af/at/bt/u/x | IEEE 802.3 ab/af/bt/u/x |
| Extender Distance | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device | Adds up to 328 ft. (100 m) to the connection distance from a PoE source to an output device |
