The Future Tense R760 M7 Rack Server
__________Based on Dual 4th generation Intel Xeon Scalable Processors, with a maximum TDP of 350W
The Future Tense R760 M7 Rack Server
Ultimate performance and versatility
The 2U, 2 socket The Future Tense enables faster time to value with peak compute performance, through optimum configurations.
R760 M7 Technical Specifications
| Model | R760 M7 |
|---|---|
| Brand | The Future Tense(JLSFT) |
| Form Factor | 2U Rackmount Server |
| Processor | Support 2x4th generation Intel Xeon Scalable Processors, with a maximum TDP of 350W |
| Memory Slot | 32 DDR5 memory slots, up to 4800MHz, support for multiple protection modes such as memory ECC, memory mirroring, memory hot standby, support for additional expansion of 16 memory slots through CXL Support up to 16 Intel R Optane R persistent memory PMem300 series |
| Storage Controller | Supports multiple storage solutions such as pass-through, RAID0, 1, 10, 5, 50, 6, 60, etc. When configuring the RAID controller, it can support Cache super capacitor protection, provide RAID level migration, disk roaming, self-diagnosis, Web remote settings and other functions, and support RAID card safe startup |
| Storage | Supports up to 20 3.5-inch or 43 2.5-inch hard drives, and is compatible with up to 36 NVMe hard drives Supports up to 36 E1.s or 36 E3.s slots Built-in support for 2 SATA/PCIe M.2, 1 onboard eMMC chip Onboard supports up to 16 SATA hard drives, no external controller required |
| Network Ports | Network card: 1 0CP 3.0, with NCSI function 0CP3.0 can be equipped with 2*1GE, 2*10GE, 2*25GE, 2*100GE, 2*200GE and other interfaces |
| Other Interfaces | Chassis rear: 1 RJ-45 management port, 2 USB 3.0 ports, 1 VGA port Chassis front: 2 USB 3.0 ports Chassis interior: 1 built-in USB 3.0 port |
| Power Supply | Optional 1300W/2000W/2200WCRPS high-efficiency platinum hot-swappable power supply, supports 1+1 redundancy, voltage range 100-240Vac (please refer to the power input value on the host nameplate label |
| Cooling | 8 hot-swappable fan modules, supporting N+1 redundancy |
| Management function | Integrated BMC chip, provides 1 1Gbps RJ45 management port, supports Redfish, SNMP, PMI2.0 and other standard interfaces; based on iKW/HTML5 remote management interface, provides comprehensive fault diagnosis, automatic operation and maintenance, remote management functions; supports BMC dual flash redundant backup |
| Operating System | Supports Microsoft Windows Server, Redhat Enterprise Linux, SUSE Linux, Ubuntu, VMware EXSI. etc |
| Product Dimensions | 796mm (L) x 435mm (W) x 43mm (H) |
| Weight | Maximum weight 25kg. |
