Specifications: Power consumption: 1.3 watts via POE
Forwarded PoE Power:
Up to 75 watts depending on standard
Maximum current 0.7 amps on data pairs
Maximum current 1.5 amps on spare pairs
PoE Standards:
IEEE 802.3af POE (15W) and IEEE 802.3at at POE Plus (2-event signature) (25-30W)
IEEE 802.3bt POE (to 75W)
Custom POE (incl. "always-on 48V" and "4-pair" POE)
Ethernet Interface:
Two independently auto-configuring 10/100 ports
(10Base-T / 100Base-TX, half / full duplex)
Patch or crossover cables supported
LEDs Status indicators:
Green LED - shows POE Power good
Yellow LED - shows Ethernet link / activity
Dimensions: 1.22" x 8.27" x 1.97"
Weight: 0.23 lb.
Mounting: 2/4 Bolt 7mm mounting holes. On 50/60mm centres
Operating temperature: -40 degree C to 70 degree C [-40 degree F to 158 degree F]
Relative humidity: Up to 85%, non-condensi...
Specifications: Cable Type: Fiber Optic
Cable Length: 3.28 ft
Connector on First End: 1 x SFF-8431 SFP+
Connector on Second End: 1 x SFF-8431 SFP+
Device Supported: Network Device
Compatibility: Cisco 10GBASE SFP+ Modules
Certifications & Standards:
MSA
ELV
Specifications: Connector type: SFP+ to SFP+
Cable length: 5 m / 16.4 ft
Cable jacket: PVC
Jacket OD: 3.0 mm
Wavelength: 850 nm
Supported data rates: 10 / 1 Gbps
Jacket color: Aqua
Ambient operating temperature: 0 to 70° C (32 to 158° F)
Specifications: Interfaces/Ports:
4 x RJ-45
1 x RJ-45
Data Transfer Rate: 230 Kbps Serial
Management:
Telnet
SNMP
Digi Port Authority-Remote
HTTP for easy browser configuration
Status Indicators: Link / Power
Input Voltage:
100 V AC to 240 V AC
9 V DC to 30 V DC
Input Current:
400 mA 12 V DC
500 mA 9 V DC to30 V DC
Specifications: PoE + Data Port (out):
Supports half / full-duplex operation
10/100/1000BASE-T port
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3at compliant
IEEE 802.3af compliant
IEEE 802.3ab compliant
Data Port (in):
Supports half / full-duplex operation
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliant
10/100/1000BASE-T port
LED Indicators:
Blue: Power On
Green: Link On
Power:
Power Adapter: 54 V / 0.6 A
Max Consumption: 32.4 watts
Output: 0.6 A at 54 V
Temperature:
Operating: 0 to 50 degree C (32 to 122 degree F)
Storage: -30 to 70 degree C (-4 to 158 degree F)
Humidity:
Operating: 5% to 95% non-condensing
Storage: 5% to 95% non-condensing
Specifications: Video Channel: 1 channel bi-direction
Signal Mode: NTSC / PAL / SECAM
Video Connector: BNC
Video Bandwidth: 60 MHz
Video Input / Output Voltage: 1.0 Vpp / typical peak-to-peak value
Video Input / Output Impedance: 75 ohm / unbalanced interface
Supported Video Type:
1080p: AHD / TVI / CVI
480p: CVBS
Video Digital Bit Width: 8/10 bit
Differential Gain (DG): < 1.3% (typical value)
Differential Phase (DP): < 1.3 degree (typical value)
SNR Weighted: > 67 dB (typical value)
Data Channel: 1 channel
Physical Protocol: RS485
Operation Mode: Simplex
Data Connector: 3-pin terminal block with screw clamps
Data Rate: DC-115.2 Kbps
Bit Error Rate (BER): < 10ns
LED Indicators:
Power
Video
Link (fiber optic)
Power Requirement: 5V DC, 2A
Power Consumption: 4.8 watts (maximum)
Mechanical: Metal
Installation: Wall-mountable, DIN-rail (with optional...
