Quick View
HDMI Over Cat6 Extender Kit Splitter/2x Pigtail Receivers 4K PoC- Type: HDMI over Ethernet
- Max Extend Distance: 230 feet
- Color: Black
- Specifications: Ports: 2
Side A - Connector 1: HDMI (FEMALE)
Side A - Connector 2: (2) RJ45 (FEMALE)
Side B - Connector 1: (2) RJ45 (FEMALE)
Side B - Connector 2: (2) HDMI (MALE)
Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 2
Video Ports: (2) RJ45 (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Supported Resolutions: 1280x720 (720p); 1920x1080 (1080p); 1920x1200; 2560x1600; 3840x2160 (4K)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Input: HDMI
Audio Output: HDMI
Audio Specification: True uncompressed 7.1 Channel digital audio
- Model #: B127A-002-BHPH2

Quick View
Black Box JPM398A Wallmount Mini DIN Rail Fiber Enclosure - 1-Slot Adapter- Type: Wallmount Mini DIN Rail Fiber Enclosure - 1-Slot Adapter
- Color: Black
- Specifications: Non-locking door can be removed providing complete access to the enclosure.
DIN Rail mounting bracket is removable.
Enclosure can be mounted five ways.
There are three possible cable entry points for the fiber.
Enclosure includes internal cable management.
- Dimensions: 2.00" x 5.30" x 5.50"
- Model #: JPM398A

Quick View
Aten VK248 8-Port Relay Expansion Box for VK2100- Color: Black
- Specifications: Interfaces
Relay
8 normally open relays (8 x 2-pole terminal block)
Contact Rating: Max 24 VDC, 2A
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power
Consumption 5 VDC, 10 W (Adapter); 48 VDC, 13 W (PoE, PoE 802.3 AF/AT compatibility)
Output 12 VDC, 300 mA
- Dimensions: 1.65" x 2.98" x 7.87"
- Weight: 1.43 lbs.
- Model #: VK248

Quick View
ATEN VK224 4-Port Serial Expansion Box- Color: Black
- Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
- Dimensions: 1.65" x 2.98" x 5.12"...
- Model #: VK224

Quick View
Tripp Lite 2-Port HDMI Over Cat5 Cat6 Extender Kit Power Over Cable 1080p (B126-2P2M-POC)- Color: Black
- Connector A: Side A - Connector 1: 1 x HDMI (FEMALE)
Side A - Connector 2: 2 x RJ45 (FEMALE)
- Connector B: Side B - Connector 1: 2 x RJ45 (FEMALE)
Side B - Connector 2: 2 x HDMI (MALE)
- Package Contents: Transmitter unit
2 x Receiver units
2 x USB Micro-B cables, 1 ft.
External power supply w/NEMA 1-15P plug and 5 ft. cord (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
Mounting hardware
Owner’s manual
- Model #: B126-2P2M-POC

Quick View
Black Box VX-HDMI-TP-70M 70M 4K Hdmi Ir Extender- Type: HDMI Extender
- Max Extend Distance: 70m
- Specifications: Connectors
Transmitter: (1) HDMI Input, (1) RJ-45 Output, (2) IR (1 in, 1 out); Receiver: (1) RJ-45 Input, (1) HDMI Output, (2) 3.5-mm IR emitter jacks (in/out)
Distance: 230 ft. (70 m) maximum
Power Output: 12 VDC
Video Bandwidth: HDMI up to 10.2Gps, including support for 1080p 60, Deep Color, HD-3D, 4Kx2K video, HD Audio Formats and Audio Return Channel
- Connector A: Transmitter: 1 x HDMI Input, 1 x RJ-45 Output, 2 x IR (1 in, 1 out)
- Model #: VX-HDMI-TP-70M
