Barcode Type: Codabar, Code 128, Code 128-A, Code 128-C, Code 128-B, Code 11, Code 39, Code 93, EAN-13, EAN-14, EAN-8, EAN-13 With 2 or 5 Digit Extension, EAN-8 With 2 or 5 Digit Extension, German Post Code, Industrial 2 of 5, Interleaved 2 of 5, Japan Postal, LOGMARS, MSI-3, MSI, Plessey, POSTNET, RSS, Standard 2 of 5, UCC/EAN 128, UPC 2 or 5 Digit Extension, EAN With 2 or 5 Digit Extension, UPC-A, UPC-E, UPC-A with 2 or 5 Digit Extension, UPC-E with 2 or 5 Digit Extension, Aztec Code, Codablock, Code 49, Data Matrix, Macro PDF-417, Maxi Code, Micro PDF-417, PDF-417, QR Code, GS1 DataBar
Media Type: Black Bar, Black Mark, Continuous Label, Continuous Receipt, Die-cut Label, Fanfold, Gap, Perforated Label, Notched, Receipt, Roll Fed, Tag, Tag Stock, Direct Thermal Label, Wristband
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered -in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate? Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – ...
Media Type: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
Media sizes supported: Maximum Label Length: 39.0 in./991 mm
Maximum Label and Media Width: 4.65 in./118 mm
Media Roll Size: 5.00 in./127 mm outer diameter Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters
Thickness: 0.003 in./0.08 mm - 0.012 in./0.305 mm (tear-off mode only)
Print Size: 4" Print width
Interface: USB, USB HOST, Modular Connectivity Slot
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered -in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate? Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – ...
