Server Barebones - Showing 1 - 24 of 840 Products
SUPERMICRO SYS-E102-9AP-L 3.5" SBC Server Barebone FCBGA 1296 DDR3L up to 1866 ...
- CPU Type: Intel Atom Processor E3930 Single Socket FCBGA 1296 supported CPU TDP support 65W
- Max Memory Supported: Up to 8GB Unbuffered non-ECC SO-DIMM, DDR3L-1866 MHz, in 1 x DIMM slot
- PCI Express: 1 x Full size Mini-PCIe (1 x USB 2.0, 1 x PCIe Gen2)
- Number of LAN: Dual LAN with Intel I210IT
- Max. Power: Lockable 12V DC 40W power adapter
- Dimensions: 1.72" x 7.48" x 4.72"
- Weight: 2.65 lbs.
- Model #: SYS-E102-9AP-L
- Item #: 9B-16-139-267
- Return Policy: Standard Return Policy
GIGABYTE H262-Z61 2U Rackmount Server Barebone Socket SP3 DDR4 3200
- CPU Type: Supports AMD EPYC 7002 series processor family Compatible with AMD EPYC 7001 series processor family
- Installed CPU: No CPU Installed
- Max Processors: 2 per node (4 node)
- Memory Slots: 16 x DIMM slots per node (4 node)
- Installed Memory Size: No Memory Installed
- Channel Supported: 8 Channel
- Installed HDD: No Storage Installed
- M.2: 2 x M.2 slots from CPU_0 and CPU_1 per node (4 node): - M-key - PCIe Gen3 x4 - Supports NGFF-2242/2260/2280/22110 cards - CPU TDP is limited to 155W if using M.2 device
- Model #: H262-Z61
- Item #: 9B-16-202-104
- Return Policy: Standard Return Policy
ASRock Rack 1U4L4E-EGS/2T 1U Rackmount General Purpose Server Barebone Intel Single ...
- Model #: 1U4L4E-EGS/2T
- Item #: 9B-16-775-107
- Return Policy: Standard Return Policy
iStarUSA D-313SE-C246-1 3U Intel Xeon E-2100 UP Rackmount Server Barebone
- CPU Type: Supports Intel Xeon E-2100 Processors
- Memory Slots: 4 x U Dimm
- Max Memory Supported: 128GB
- Serial ATA: 8x SATA3 6Gb/s (SATA0-7, SATA0 supports SATA DOM, and is shared with M.2(PCIE3.0(x4))/ SATA3)
- GPU/VPU: ASPEED AST2500
- Video Memory: DDR4 32MB
- PCI Express: 1x PCIe 3.0 x16 1x PCIe 3.0 x8 1x PCIe 3.0 x4
- Number of LAN: GLAN by Intel i210 Realtek RTL8211E for dedicated management GLAN
- Model #: D-313SE-C246-1
- Item #: 9B-16-215-802
- Return Policy: Standard Return Policy
ASRock Rack 2U2E-F/ICX2 2U Rackmount Server Barebone 1+1 Socket P+ (LGA 4189) Intel ...
- CPU Type: Intel Xeon
- Installed CPU: No CPU Installed
- Max Processors: 2
- Memory Slots: 32 x 288Pin
- Installed Memory Size: No Memory Installed
- Installed HDD: No Storage Installed
- M.2: 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 2280/2260/2242 form factor
- GPU/VPU: Aspeed AST2500
- Model #: 2U2E-F/ICX2
- Item #: 9B-16-775-045
- Return Policy: Standard Return Policy
Asrock Rack 2U12L2S-ROME/2T 2U Rackmount Storage Server Barebone AMD EPYC 7003 ...
- CPU Type: Supports AMD EPYC 7002 and 7001 series processors
- Installed CPU: No CPU Installed
- Memory Slots: 8 x 288Pin
- Installed Memory Size: No Memory Installed
- GPU/VPU: Aspeed AST2500
- PCI Express: 1 FHFL (PCIe4.0 x16) via 4UXG_SL2P* 1 FHFL (PCIe4.0 x16) via RBBA* 1 FHHL (PCIe4.0 x16) via RBBA 1 FHHL (PCIe4.0 x8) via RBBA * Please contact ASRock Rack sales if dual slot GPU cards support needed
- Max. LAN Speed: 10 Gigabit
- Max. Power: 800W
- Model #: 2U12L2S-ROME/2T
- Item #: 9B-16-775-012
- Return Policy: Standard Return Policy
ASRock Rack 2U24E-EGS2 2U Rackmount Storage Server Barebone Intel Dual Socket 4th Gen ...
- Model #: 2U24E-EGS2
- Item #: 9B-16-775-106
- Return Policy: Standard Return Policy
Asrock Rack 1U2LW-X570 1U Rackmount Server Barebone 2 Bays Single Socket AM4 PGA ...
- CPU Type: Supports: AMD Ryzen 5000 and 3000 Series Desktop Processors AMD Ryzen 4000 and 3000 G-Series Desktop Processors with Radeon Graphics AMD Ryzen PRO 5000, 4000 and 3000 Series Desktop Processors
- Installed CPU: No CPU Installed
- Memory Slots: 4 x 288Pin
- Installed Memory Size: No Memory Installed
- Installed HDD: No Storage Installed
- GPU/VPU: Aspeed AST2500
- PCI Express: Supports 1 FHHL PCIe4.0 x16* via RB1UX16_G4 *Supports PCIe3.0 x8 when using AMD Ryzen 3000 G-Series Desktop Processors with Radeon Graphics *Supports PCIe3.0 x16 when using AMD Ryzen 4000 G-Series Desktop Processors with Radeon Graphics
- First LAN: Intel I210
- Model #: 1U2LW-X570
- Item #: 9SIA4N9JSW3399
- Return Policy: Platinum Micro Inc. Return Policy
Supermicro SYS-1029P-MT Barebone 1U Rackmount Super Server, Intel C621 Chipset
- Model #: SYS-1029P-MT
- Item #: 9B-1B0-002W-00051
- Return Policy: Standard Return Policy
ASUS SV RS500A-E11-RS4U-WOCPU010Z 1U AMD EPYC7003 LGA4094 DDR4 800W Brown ...
- CPU Type: Supports AMD EPYC 7002 / 7003 Series
- Installed CPU: No CPU Installed
- Max Processors: 1
- CPU Features: Supports 3rd Gen AMD EPYC processors with AMD 3D V-Cache technology
- Memory Slots: 16 x 288Pin
- Installed Memory Size: No Memory Installed
- Max Memory Supported: 4TB
- Channel Supported: 8 Channel
- Model #: RS500A-E11-RS4U-WOCPU010Z
- Item #: 9B-293-0008-001B0
- Return Policy: Standard Return Policy
SUPERMICRO SYS-740GP-TNRT 4U Tower 4U Rackmountable Tower Dual Processor (3rd Gen ...
- CPU Type: Supports 3rd Gen Intel Xeon Scalable processors
- Installed CPU: No CPU Installed
- Max Processors: 2
- Memory Slots: 16 x 288Pin
- Installed Memory Size: No Memory Installed
- Max Memory Supported: 6TB
- ECC Supported: Yes
- Installed HDD: No Storage Installed
- Model #: SYS-740GP-TNRT
- Item #: 9SIV0Z4JS86911
- Return Policy: Compute4Less Corp Return Policy
GIGABYTE 4th Gen Intel® Xeon® Scalable Server System - 1U UP 12-Bay NVMe/SATA/SAS ...
- Model #: R163-S32-AAC1
- Item #: 9B-16-202-186
- Return Policy: Standard Return Policy
ASUS RS700-E11-RS4U-16W10G 1U Rackmount Server Barebone LGA 4677 Intel C741 ...
- CPU Type: Intel Xeon Processor Scalable Family
- Installed CPU: No CPU Installed
- Memory Slots: 32 x 288Pin
- Installed Memory Size: No Memory Installed
- Installed HDD: No Storage Installed
- Serial ATA: 4 x NVMe/SATA/SAS* (HBA//RAID card is required to support SAS hard drives)
- M.2: 2
- PCI Express: Up to 3+1 PCIe slot 1 x OCP 3.0 or PCIe G5 x16 FHFL 1 x PCIe G5 x16 FHFL 1 x PCIe G5 x8. LP (Internal) 1 x PCIe G5 x16, LP
- Model #: RS700-E11-RS4U-16W10G
- Item #: 9B-16-110-197
- Return Policy: Standard Return Policy
Asrock Rack 2U12L-ICX2 2U Rackmount Storage Server Barebone Dual Socket P+ (LGA ...
- Model #: 2U12L-ICX2
- Item #: 9B-16-775-089
- Return Policy: Standard Return Policy
ASRock Rack 1U12E-GENOA/2L2T 1U Rackmount Storage Server Barebone AMD Single ...
- Model #: 1U12E-GENOA/2L2T
- Item #: 9B-16-775-101
- Return Policy: Standard Return Policy
AsRock Rack 1U8S4E-GENOA/2T 1U Rackmount Storage Server Barebone Single Socket SP5 ...
- Model #: 1U8S4E-GENOA/2T
- Item #: 9B-16-775-093
- Return Policy: Standard Return Policy
Tyan B8056T70V8E6HR , 2U1S Storage Server, hybrid NVMe/SAS/SATA BP ,Single Socket ...
- Model #: B8056T70V8E6HR
- Item #: 9B-16-152-204
- Return Policy: Standard Return Policy
Tyan BS8251T83E8HR-2T-N 2U Barebone and AMD Dual Milan 7373X 16-Core CPU combo ...
- Series: BS8251T83E8HR-2T-N-1
- CPU Type: Supports AMD EPYC 7002/7003 Series Processors
- Installed CPU: 2 x AMD 7773X, Milan X, 64 cores, 128 threads, 2.30 GHz
- Max Processors: 2
- Memory Slots: 16 x 288Pin
- Installed Memory Size: No Memory Installed
- Max Memory Supported: Up to 2,048GB RDIMM / 4,096GB LRDIMM 3DS
- Channel Supported: 8 Channels per CPU
- Model #: BS8251T83E8HR-2T-N-1
- Item #: 9B-16-152-202
- Return Policy: Standard Return Policy
ASUS RS500A-E12-RS4U Server Barebnone, AMD EPYC™ 9004 single-processor 1U server ...
- CPU Type: Supports AMD EPYC 9004 Series Processors (up to 400W)
- Installed CPU: No CPU Installed
- Max Processors: 1
- CPU Features: Supports 4th Generation AMD EPYC Processors with AMD 3D V-Cache technology AMD EPYC 9004 Series Processors (Air cool with EVAC up to 400W)
- Memory Slots: 24 x 288Pin
- Installed Memory Size: No Memory Installed
- Max Memory Supported: 6TB
- Channel Supported: 12 Channel
- Model #: RS500A-E12-RS4U-8TW
- Item #: 9B-16-110-178
- Return Policy: Standard Return Policy
ASRock Rack 1U8S2E-ICX/2T 1U Rackmount Server Barebone LGA 4189 Intel C621A DDR4 ...
- CPU Type: Supports 3rd Gen Intel Xeon Scalable processors
- Installed CPU: No CPU Installed
- Max Processors: 1
- Memory Slots: 8 x 288Pin
- Installed Memory Size: No Memory Installed
- Installed HDD: No Storage Installed
- GPU/VPU: Aspeed AST2500
- Video Memory: 16MB DDR4
- Model #: 1U8S2E-ICX/2T
- Item #: 9B-16-775-079
- Return Policy: Standard Return Policy
AsRock Rack 1U2N2G-ROME/2T 1U Rackmount Multi-node GPU Server Barebone Socket SP3 ...
- Model #: 1U2N2G-ROME/2T
- Item #: 9B-16-775-098
- Return Policy: Standard Return Policy
ASRock Rack 1U10E-ROME/2T Single Socket SP3/ DDR4/ 1U Rackmount Server Barebone ...
- Model #: 1U10E-ICX2
- Item #: 9B-16-775-086
- Return Policy: Standard Return Policy
What are Barebones Server Systems?
Introduction
Barebones server systems are server kits that only include the motherboard, case, and power supply. The processor, memory, hard drives, and other components have to be purchased separately. While it is more labor intensive to manually assemble a server, barebones server systems do have advantages over purchasing a customized server from a major manufacturer.
System Components
With barebones server systems, you already have the motherboard, chassis, and power supply. The components that you need to purchase separately are the processor, memory, and hard drives among other others. Caution should be exercised when purchasing those components however, as there are differences between consumer-grade and server-grade components.
CPU
Compared to a desktop processor, a server processor will run cooler, use less power, and have other small differences that allow them to run for longer periods of time. Performance-wise, desktop and server processors are relatively similar.
Memory
Memory for servers typically support a technology known as error correction code (ECC). It is a feature that allows the memory to perform self-checks for errors without requiring action from the user or processor. ECC is important for servers, where data corruption cannot be tolerated.
Hard Drives
Because servers are designed to provide services and data for networked computers, the storage drives for that data are very important. For use with barebones server systems, enterprise-grade hard drives are recommended. And to lower the chances of losing data, the hard drive should be set up in a redundant array of independent disks (RAID) configuration.
What Type of Barebones Server System can I Get?
There are two types of barebone server kits, tower and rack-mounted. A barebones tower kit resembles a desktop computer while a rack-mounted server looks quite different and is installed inside a rack-mount server chassis.
They use the same hardware and the major differences are the case and motherboard. If the server will be your organization’s first, then a tower server kit is ideal. For larger organizations, rack-mounted servers will be more advantageous as they have better cable management and are more space-efficient.
Should I Assemble a Barebones Server System or Order a Customized Server?
With a barebones server kit, you can potentially have the server up and running in a much shorter amount of time than if you ordered a customized system from a manufacturer. The time it takes for a manufacturer to process an order depends on two factors. The first is the availability of the components you request, and second is the time required to assemble those components.
Also, you have much more control over the components used when you assemble the server in-house. For example, when ordering a customized server, you can dictate the size and speed of the hard drives but you usually cannot choose a specific model. With barebones server systems, you have the flexibility to choose components from whatever manufacturer you wish.
