Server Chassis - Showing 1 - 24 of 11349 Products

Filter (0)
iStarUSA DAGE312UTL-NAS Black Steel 3U Rackmount NAS 3U 12-bay 3.5" SATA 6.0 Gb/s ...
Save: $767.74 (28%)
$2,699.95
$1,932 .21
Save: $767.74 (28%)
$2,699.95
$1,932 .21
Rosewill RSV-L4000U 4U Server Chassis Rackmount Case | 8 3.5" HDD Bays, 3 5.25" Devices | ...
Save: $50.00 (20%)
$249.99
$199 .99
Free Shipping
Save: $50.00 (20%)
$249.99
$199 .99
Rosewill RSV-L4500U 4U Server Chassis Rackmount Case | 15 3.5" HDD Bays | E-ATX ...
Save: $40.00 (15%)
$269.99
$229 .99
Free Shipping
Save: $40.00 (15%)
$269.99
$229 .99
Rosewill RSV-Z2600U 2U Server Chassis Rackmount Case | 4 3.5" HDD Bays | Micro-ATX ...
Save: $30.00 (15%)
$199.99
$169 .99
Free Shipping
Save: $30.00 (15%)
$199.99
$169 .99
Rosewill RSV-L4412U 4U Server Chassis Rackmount Case | 12 Hot Swap 3.5", 2.5" SATA I, ...
Save: $140.00 (28%)
$499.99
$359 .99
Free Shipping
Save: $140.00 (28%)
$499.99
$359 .99
BLACK 1U MINI SC505 CHASSIS W/
Save: $1.26
$161.25
from $159 .99
Free Shipping
Save: $1.26
$161.25
from $159 .99
Choose From 5 Sellers
Rosewill RSV-R4200U 4U Server Chassis Rackmount Case | 11 3.5" Bays, 3 2.5" Devices| ...
Save: $10.00
$189.00
$179 .00
Free Shipping
Save: $10.00
$189.00
$179 .00
iStarUSA D-200L Black Aluminum / Steel 2U Rackmount High Performance Chassis 2 External ...
$218 .99
Athena Power RM-3U300PR80U2 Black Brushed Aluminum Front Bezel / 1.2mm SECC 3U ...
$330 .99
Free Shipping
Tripp Lite SRWO16US Wallmount Open Frame Rack 16U 2-Post Hinged Front Heavy Duty
$875 .99
Free Shipping
SKB 8RU Space Stack with Roto Rolling Rack, Wheels and Handle #1SKB-R8UW
$364 .99
Free Shipping
$364 .99
Sold by: Adorama
iStarUSA D-214-MATX Black Steel 2U Rackmount Chassis 2 External 5.25" Drive Bays
from $86 .99
Free Shipping
from $86 .99
Choose From 3 Sellers
SUPERMICRO CSE-847E16-R1400LPB Black 4U Rackmount Server Case 1400W Redundant
from $2,199 .00
from $2,199 .00
Choose From 3 Sellers
Aigo YOGO M2 PRO Titanium Gray Gaming Shoebox Computer Case E-ATX/ATX ...
from $185 .88
from $185 .88
Choose From 2 Sellers
Supermicro CSE-829BTQ-R920WB 2U Chassis
$1,319 .99
Free Shipping
1U server case / standard 19 "rack-mounted server case / suitable for various motherboards ...
from $281 .77
Free Shipping
from $281 .77
Choose From 2 Sellers
CHENBRO RM41300-F1 Black 1.2mm SGCC, ABS-HB 4U Rackmount No Power Supply 4U ...
from $240 .99
Free Shipping
from $240 .99
Choose From 5 Sellers
In Win IW-RF100S-S265 1U Short-depth Rackmount Server Chassis with Single 265W Power ...
from $162 .76
Free Shipping
from $162 .76
Choose From 4 Sellers
Supermicro SuperChassis 825TQC-600LPB (Black)
$899 .99
Free Shipping
SUPERMICRO CSE-815TQ-R700UB Black 1U Rackmount Server Case 700W Redundant
from $1,099 .99
Free Shipping
from $1,099 .99
Choose From 2 Sellers
IN WIN IW-PL052X.B3 Black Mid-Tower Server Case 4 External 5.25" Drive Bays
from $168 .19
Free Shipping
from $168 .19
Choose From 3 Sellers
IBM BladeCenter H 88525TU Stealth black 9U Rackmount Server Case
$6,288 .00
Free Shipping
CHENBRO RM24100-L2 1.0mm SGCC 2U Rackmount Advanced Industrial Server Case 1 ...
from $170 .99
from $170 .99
Choose From 4 Sellers
TOPOWER TP-2166B-500S-H3 2U Rackmount IPC Server Chassis w/ 500W Power Supply 2 ...
$149 .99
Free Shipping

Introduction to Server Chassis

Introduction

A server case is an enclosure that houses important components such as the motherboard, processor, storage drives, network interface controllers, and more. There are several types of server cases and the size of your organization’s network influences the type of case you use. Below, NeweggBusiness will outline the main types of server cases, chassis, and enclosures.

Types of Server Cases

Tower

A common type of computer case for desktops and servers, it is available in a variety of sizes and designs. Common characteristics of tower cases include a vertically mounted motherboard, front-facing optical drives, and input/output connections in the rear. A tower case is ideal for organizations with smaller environments. Compared to other types of servers, they are more economical choices.

Pedestal

Pedestal server cases look very similar to towers, but there are a few differences that make them more suited for server use. A major distinction is that many pedestal enclosures are designed to accommodate larger motherboard standards, such as Server System Infrastructure (SSI) boards. Some pedestal enclosures support passive cooling for the processor, allowing them to run quieter. Passive cooling for a processor means that it does not require a fan for cooling, relying only on a heat sink and low case temperatures.

Rackmount

A rackmount server case is an enclosure with standardized dimensions to fit a server rack. It is geared towards organizations that need to densely pack multiple servers into one area. Because rackmount servers can generate great amounts of heat, having them in a temperature-controlled room is recommended.

When shopping for a rackmount server chassis, you will have several sizes to choose from. The next section will detail the most common standards.

Rackmount Sizing

Server racks can be either 19 inches wide or 23 inches wide, with 19 inch racks being slightly more common. Rackmount cases can usually be adapted for both 19 and 23 inch racks with use of mounting brackets.

For measuring the height of server equipment, rack units are used. One rack unit is equal to 1.75 inches and is often shortened to U or RU. A server rack is typically 42U tall, though there are many other sizes available.

The most common rackmount server case sizes are 1U, 2U, 3U, and 4U. A 1U server case is the smallest available and is the most economical. Larger options such as 2U and 3U are designed to give additional space to accommodate more processors, memory, and hard drives. A 4U chassis allows for even more space for components and some can fit as many as 24 hard drives. The downsides of larger rack units are higher cost, more heat, and more power requirements.

Conclusion

You should purchase a server case that fits the needs of your organization, but at the same time prepare for future growth. If your organization already utilizes several tower or pedestal cases, consider consolidating them into a rackmount setup. But if your organization needs more computing power from its rack servers, consider replacing any 1U server with a 2U or larger case to add more processors and memory.



By NeweggBusiness Staff
