Specifications: Interface:
"PoE (Power + Data)" Input Port : 1 x RJ-45 10/100/1000Base-T
"Data" Out Port: 1 x RJ-45 10/100/1000Base-T
DC Out Plug Connector: 1 removable 4-Pin terminal block
LED Indicator:
System: Power Ready x 1 (Green)
Network Cable:
10/100/1000Base-T: 4-Pair UTP Cat. 5, 5e, 6
Distance up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000 Mbps (vary on Ethernet device attached)
DIP Switch: 12V DC / 24V DC output voltage
Power Input: 802.3at PoE 48~56V DC
Power Output: 12V / 24V DC, max 2A (adjustable)
Enclosure: IP30 metal case
Installation: DIN rail kit and wall mount ear
ESD / EFT Protection: 6 KV DC
PoE Standard: IEEE 802.3at High Power over Ethernet
Number of devices that can be powered: 1 or 2 (Vary on device's power requirement; DC1 + DC2 cannot be over 25 watts.)
...
Specifications: Cable Type: Fiber Optic
Cable Length: 3.28 ft
Connector on First End: 1 x SFF-8431 SFP+
Connector on Second End: 1 x SFF-8431 SFP+
Device Supported: Network Device
Compatibility: Cisco 10GBASE SFP+ Modules
Certifications & Standards:
MSA
ELV
Specifications: Connector type: SFP+ to SFP+
Cable length: 5 m / 16.4 ft
Cable jacket: PVC
Jacket OD: 3.0 mm
Wavelength: 850 nm
Supported data rates: 10 / 1 Gbps
Jacket color: Aqua
Ambient operating temperature: 0 to 70° C (32 to 158° F)
Specifications: Flush-frame acoustic ceiling bracket for ZoneFlex R710.
Flush-frame only - not applicable for standard (recessed-frame) acoustic ceiling.
Kit Content:
1 x Mounting bracket
2 x Mounting guide
Specifications: Power Method: 100-240V AC / 50-60 Hz, Universal Input
Power Supply:
54V, 150W AC/DC
Installed in PSU 1
Maximum Power Output:
150W (1 PSU module)
300W (2 PSU modules @ 150 W each)
LEDs:
Power: System on / off
Ethernet: Management port link
PSU: PSU1+PSU2, PSU1 / PSU2
Networking Interface: 1 x RJ-45 Fast Ethernet port
Rack Mount: Yes, 1U high
ESD/EMP Protection: Air +/- 24 kV; Contact +/- 24 kV
Specifications: Interface: LAN:
1 x RJ-45 STP, "Data" Input Port
POE: 1 x RJ-45 STP, "Data + Power" Output Port
AC Connector: 1 x AC Input power socket, IEC-320 C6
Network Cable:
Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
802.3af / at PoE(15W / 30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
LED Indicator:
System: Power x 1 (Green)
PoE Port: Active, PoE ready / In Use x 1 (Green)
Data Rate: 10/100/1000 Mbps
Unit Output Voltage: DC 50-57V, 1.2A
Power Requirements: 100-240V AC @ 50/60 Hz, 1.5A max.
Power Consumption: 60 watts max.
PoE Standard:
Ultra PoE over 4-pairs UTP,
High Power over Ethernet End-Span / Mid-Span PSE
PoE Power Supply Type: End-Span + Mid-Span
Power Pin Assignment:
Pair 1 End-Span: 1/2 (+), 3/6 (-)
Pair 2 Mid-Span: 4/5 (+), 7/8 (-)
PoE Power Output:
DC 50-57V/60-w...
Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both mid-span and end-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Ethernet Interface:
Copper:
10/100BASE-TX RJ45
auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE-in-use
LNK / ACT
ESD Protection: 4KV DC
Enclosure: Metal case
Installation: Wall mount or DIN rail with optional kit
Power Requirements: BNC Power over Coaxial Input: 44~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet Plus(802.3at Type 2)
Specifications: Interface:
"Data" Input Port: 1 x RJ-45 STP
"PoE (Data+Power)" Output Port: 1 x RJ-45 STP
Input power terminal block: 1
LED Indicator:
System: Power 1, Power 2, Fault (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
10Base-T: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000Mbps
Dimension: 1.26" x 5.31" x 3.46"
Weight: 1.05 lbs.
Unit Input Voltage: 24 - 48V DC; 24V AC
Power Consumption: 30 watts max.
Number of device can be powered: 1
Installation: DIN rail kit and wall mount ear
Alarm:
Provides one relay output for power failure,
Alarm relay current carry ability: 3A at DC 30V
Enclosure: IP30 slim type metal case
Power over Ethernet
PoE Standard: IEEE 802.3at High ...
Specifications: PoE Standard: IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High Power over Ethernet)
PoE Power Supply Type: Mid-Span / Type B
PoE Power Output: 52V DC, 510 mA, Max. 26 watts
Power Pin Assignment: 4/5 (+), 7/8 (-)
Maximum Distance: 4 units, daisy-chain installation with 500m support
Data Rate: 10/100/1000 Mbps
Switch Architecture: Store-and-Forward
Maximum Frame Size: 1552 Bytes
Flow Control:
Back pressure for half-duplex
IEEE 802.3x pause frame for full-duplex
LED Indicators:
1 x PoE IN (Green)
1 x LAN Data (Green)
1 x PoE OUT (Green)
Power Requirements: IEEE 802.3at compliant with voltage within 52V-56V DC
Power Consumption: 3.2 watts (system maximum)
