Features: HIGH POWER GIGABIT PoE SPLITTER: Power non-PoE devices using network infrastructure where power isn't available / Splits PoE connection (max 90W) into RJ45 data & DC power (terminal block)
90W POE IEEE802.3bt: Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), IEEE 802.3bt (PoE++ / Type 3); power out configured w/ DIP switch for 12/16/24/48V DC (1.5A) via terminal block
TECH SPECS: High Speed 1 Gbps / 1 x RJ45 PoE In / 1 x RJ45 Dat...
Specifications: Interface: LAN:
1 x RJ-45 STP, "Data" Input Port
POE: 1 x RJ-45 STP, "Data + Power" Output Port
AC Connector: 1 x AC Input power socket, IEC-320 C6
Network Cable:
Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
802.3af / at PoE(15W / 30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
LED Indicator:
System: Power x 1 (Green)
PoE Port: Active, PoE ready / In Use x 1 (Green)
Data Rate: 10/100/1000 Mbps
Unit Output Voltage: DC 50-57V, 1.2A
Power Requirements: 100-240V AC @ 50/60 Hz, 1.5A max.
Power Consumption: 60 watts max.
PoE Standard:
Ultra PoE over 4-pairs UTP,
High Power over Ethernet End-Span / Mid-Span PSE
PoE Power Supply Type: End-Span + Mid-Span
Power Pin Assignment:
Pair 1 End-Span: 1/2 (+), 3/6 (-)
Pair 2 Mid-Span: 4/5 (+), 7/8 (-)
PoE Power Output:
DC 50-57V/60-w...
Specifications: Interface:
"Data" Input Ports: 16 x RJ45
"Data + Power" Output Ports: 16 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000Mbps
LED
System: SYS PWR x 1 (Green), PoE Failure x 1 (Red), Fan Failure x 2 (Red)
Management port x 2: 1000 (Green), 10/100(Orange)
Per PoE Port: Ultra 60W PoE-in-use x 1 (Green), 802.3at/af PoE-in-use x1 (Orange), PoE Power Usage LED x4 (Green)
Power Requirements: 100 - 240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts (max.) / 2729BTU
Ventilation: Fan x 3
Enclosure: Metal
PoE Standard:
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE
PoE Power Supply Type: End-span / Mid-span / UPoE (Ultra PoE)
Power Pin Assignment:
Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),...
Specifications: Cable Type:
Twinaxial
Cable Length:
9.84 ft
Connector Type on First End:
SFP+ Network
Connector Gender on First End:
Male
Connector on First End Details:
1 x SFP+ Network
Connector Type on Second End:
SFP+ Network
Connector Gender on Second End:
Male
Connector on Second End Details:
1 x SFP+ Network
Conductor:
Copper
Device Supported:
Network Device
Specifications: Cable Type: SFP+
Cable Length: 9.84 ft.
Connector on First End: 1 x SFP+ Network
Connector on Second End: 1 x SFP+ Network
Data Transfer Rate: 1.25 GB/s
Compatibility: Aruba 8320 Switch Series
