Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
Specifications: Get USB connectivity anywhere.
Combine the 2-Port CATx USB Extender with Remote or Local Power
Simplified installation eliminates the need for AC power close to units.
Delivers power to hubs over CAT5 cable.
Combine with hubs to connect up to 30 devices.
Remote units provide 1A to USB port.
The USB Ultimate Extender works with all USB device types: control, interrupt, bulk, and isochronous at up to 480 Mbps.
It's ideal for a wide variety of USB devices, from printers, scanners, hard drives, audio devices, touch screens, and Web cams.
Supports all major operating systems including Windows, Mac OS, and Linux.
It's truly plug-and-play, ready to operate right out of the box.
No driver installation required.
Use it f...
Specifications: VE803T
Connectors
HDMI In: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type B Female (White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches:
EDID Selection: 1 x slide switch
LEDs
Power: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 1W
PhysicalProperties
Housing: Metal
VE803R
Connectors
HDMI Out: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type A Female(White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches
EQ Compensation: 1 x 8 position switch
LEDs
Power: 1 (Green)
HDMI: 1 (Green)
USB: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 3.9W
PhysicalProperties
Housing: Metal
Specifications: Connectors
Transmitter: (1) HDMI Input, (1) RJ-45 Output, (2) IR (1 in, 1 out); Receiver: (1) RJ-45 Input, (1) HDMI Output, (2) 3.5-mm IR emitter jacks (in/out)
Distance: 230 ft. (70 m) maximum
Power Output: 12 VDC
Video Bandwidth: HDMI up to 10.2Gps, including support for 1080p 60, Deep Color, HD-3D, 4Kx2K video, HD Audio Formats and Audio Return Channel
Connector A: Transmitter: 1 x HDMI Input, 1 x RJ-45 Output, 2 x IR (1 in, 1 out)
Connector B: Receiver: 1 x RJ-45 Input, 1 x HDMI Output, 2 x 3.5-mm IR emitter jacks (in/out)
Dimensions: Transmitter: 0.8"H x 3.1"W x 2"D (2 x 8 x 5 cm)
Receiver: 0.9"H x 3.1"W x 2.6"D (2.3 x 8 x 6.7 cm)
Weight: Transmitter: 0.4 lb. (0.2 kg)
Receiver: 0.6 lb. (0.3 kg)
Connector A: Side A - Connector 1: 1 x HDMI (FEMALE)
Side A - Connector 2: 2 x RJ45 (FEMALE)
Connector B: Side B - Connector 1: 2 x RJ45 (FEMALE)
Side B - Connector 2: 2 x HDMI (MALE)
Package Contents: Transmitter unit
2 x Receiver units
2 x USB Micro-B cables, 1 ft.
External power supply w/NEMA 1-15P plug and 5 ft. cord (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
Mounting hardware
Owner’s manual
